RT-SVX36G-EN 111
Unit Start Up
Table 36. Service test guide for component operation — Part II of II
Component
Being Tested
Component Configuration Occ
Unocc
Relay
Reheat
Sump
Pump
Sump
Heater
Dolphin
Econo
Damper
Exhaust
Damper
VFD
Output
COMPRESSOR
20 - 30 Ton
A Closed Closed 0% Default OFF OFF OFF OFF
B Closed Closed 0% Default OFF OFF OFF OFF
40 - 60 Ton
1A Closed Closed 0% Default OFF OFF OFF OFF
1B Closed Closed 0% Default OFF OFF OFF OFF
2A Closed Closed 0% Default OFF OFF OFF OFF
2B Closed Closed 0% Default OFF OFF OFF OFF
70 - 105 Ton
1A Closed Closed 0% Default OFF OFF OFF OFF
1B Closed Closed 0% Default OFF OFF OFF OFF
2A Closed Closed 0% Default OFF OFF OFF OFF
2B Closed Closed 0% Default OFF OFF OFF OFF
115 - 130 Ton
1A & 1B Closed Closed 0% Default OFF OFF OFF OFF
2A & 2B Closed Closed 0% Default OFF OFF OFF OFF
CONDENSER FANS
20 Ton
A-2B1 Closed Closed 0% Default OFF OFF OFF OFF
B-2B2 Closed Closed 0% Default OFF OFF OFF OFF
25 - 30 Ton
A-2B1 Closed Closed 0% Default OFF OFF OFF OFF
B-2B2/2B3 Closed Closed 0% Default OFF OFF OFF OFF
40 Ton
1A-2B1 Closed Closed 0% Default OFF OFF OFF OFF
1B-2B2 Closed Closed 0% Default OFF OFF OFF OFF
2A-2B4 Closed Closed 0% Default OFF OFF OFF OFF
2B-2B5 Closed Closed 0% Default OFF OFF OFF OFF
50 Ton
1A-2B1 Closed Closed 0% Default OFF OFF OFF OFF
1B-2B2/2B3 Closed Closed 0% Default OFF OFF OFF OFF
2A-2B4 Closed Closed 0% Default OFF OFF OFF OFF
2B-2B5/2B6 Closed Closed 0% Default OFF OFF OFF OFF
60 - 75 Ton
1A-2B1 Closed Closed 0% Default OFF OFF OFF OFF
1B-2B2/2B3 Closed Closed 0% Default OFF OFF OFF OFF
2A-2B4 Closed Closed 0% Default OFF OFF OFF OFF
2B-2B5/2B6 Closed Closed 0% Default OFF OFF OFF OFF
90 Ton
1A-2B3/2B14 Closed Closed 0% Default OFF OFF OFF OFF
1B-2B1/2B2 Closed Closed 0% Default OFF OFF OFF OFF
2A-2B6/2B13 Closed Closed 0% Default OFF OFF OFF OFF
2B-2B4/2B5 Closed Closed 0% Default OFF OFF OFF OFF
105 & 115 Ton
1A-2B3/2B14 Closed Closed 0% Default OFF OFF OFF OFF
1B-2B1/2B2/2B19 Closed Closed 0% Default OFF OFF OFF OFF
2A-2B6/2B13 Closed Closed 0% Default OFF OFF OFF OFF
2B-2B4/2B5/2B15 Closed Closed 0% Default OFF OFF OFF OFF
130 Ton
1A-2B3/2B14 Closed Closed 0% Default OFF OFF OFF OFF
1B-2B1/2B2/2B19/2B20 Closed Closed 0% Default OFF OFF OFF OFF
2A-2B6/2B13 Closed Closed 0% Default OFF OFF OFF OFF
2B-2B4/2B5/2B15/2B21 Closed Closed 0% Default OFF OFF OFF OFF
24, 29, 36, 48, 59, 73, 80, 89 Ton
1A Closed Closed 100% Default OFF OFF OFF OFF
SUPPLY FAN Closed Closed 100% Unocc OFF OFF OFF OFF
RETURN FAN Closed Closed 100% Unocc OFF OFF OFF OFF
EXHAUST FAN Closed Closed 100% Default OFF OFF OFF OFF
To Next Page
