RT-SVX36G-EN 39
Installation
Table 9. Electrical entrance data
Unit Size
(AC/EC)
Dimensions
FGHJKLMN
20, 25 & 30 Ton 8 7/32" 6 31/32" 15 21/32" 13 21/32" 9 17/32" 8 1/2" 18 1/16" 19 9/16"
40-75 / 24-89 Ton 8 15/16” 7 15/16” 17 7/8" 15 7/8" 9 29/32" 10 3/16” 20 13/32" 22 5/32"
Table 10. CPVC dimensional data
Unit Size Dimensions (Note)
(AC/EC) Furnace Size/MBH Length Height
20 & 25, 24 & 29 Ton
Low = 235 195-5/32" 9-5/32"
High = 500 195-5/32" 9-5/32"
30, 36 Ton
Low = 350 195-5/32" 9-5/32"
High = 500 195-5/32" 9-5/32"
40, 48 Ton
Low = 350 240-1/8" 9-5/32"
High = 850 231-1/8" 9-5/32"
50-75, 59-89 Ton
Low = 500 240-1/8" 9-5/32"
High = 850 231-1/8" 9-5/32"
Note: The length dimension is from the exhaust end of the unit. The height dimension is from the bottom of the unit base rail.
