Table 5. L8V1A060U3VS Heating Airflow
L8V1A060U3VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure (iwc)
with Filter
Heating Capacity = 48,100
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating
Low 830
CFM 857 850 843 836 829
Temp. Rise
51 52 52 53 54
Watts 51 102 153 204 255
Medium Low 960
CFM 993 981 970 958 946
Temp. Rise
44 45 46 47 47
Watts 76 131 186 241 296
Medium
(a)
990
CFM 1014 1010 1005 1001 996
Temp. Rise
43 44 44 44 45
Watts 82 139 197 255 312
High
1130
CFM 1163 1153 1143 1133 1124
Temp. Rise
38 38 39 39 40
Watts 120 182 244 307 369
Table 6. L8V1A060U3VS Cooling Airflow
L8V1A060U3VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter
Outdoor
Tonnage - ODT
Airflow Setting
(CFM/Ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
1.5
450
CFM / WATTS 718 / 56 706 / 96 694 / 140 682 / 185 670 / 232
420
CFM / WATTS 673 / 49 661 / 87 649 / 129 637 / 173 625 / 219
400
CFM / WATTS 642 / 44 630 / 82 618 / 122 606 / 165 594 / 210
370
CFM / WATTS 596 / 38 584 / 74 572 / 113 560 / 154 548 / 198
350
CFM / WATTS 565 / 35 553 / 69 541 / 107 529 / 147 517 / 190
330
CFM / WATTS 534 / 31 522 / 65 510 / 101 498 / 141 485 / 183
310
CFM / WATTS 502 / 28 490 / 60 478 / 96 466 / 135 454 / 176
290
CFM / WATTS 470 / 25 458 / 56 446 / 91 434 / 128 422 / 169
2.0
450
CFM / WATTS 938 / 103 926 / 153 914 / 204 902 / 258 890 / 313
420
CFM / WATTS 881 / 88 868 / 136 856 / 185 844 / 237 832 / 289
400
CFM / WATTS 842 / 80 830 / 125 818 / 173 806 / 223 794 / 274
370
CFM / WATTS 783 / 67 771 / 111 759 / 156 747 / 204 735 / 253
350
CFM / WATTS 743 / 61 731 / 102 719 / 146 707 / 192 695 / 240
330
CFM / WATTS 703 / 53 691 / 93 679 / 136 667 / 181 655 / 228
310
CFM / WATTS 663 / 47 651 / 86 638 / 127 626 / 170 614 / 216
290
CFM / WATTS 622 / 41 610 / 78 598 / 118 586 / 160 574 / 205
2.5
450
CFM / WATTS 1146 / 172 1134 / 230 1122 / 291 1110 / 352 1098 / 416
420
CFM / WATTS 1078 / 146 1066 / 202 1054 / 259 1042 / 318 1030 / 379
400
CFM / WATTS 1032 / 131 1020 / 184 1008 / 240 996 / 297 984 / 356
370
CFM / WATTS 962 / 110 950 / 160 938 / 213 926 / 267 914 / 323
350
CFM / WATTS 914 / 97 902 / 145 890 / 196 878 / 249 866 / 303
330
CFM / WATTS 866 / 85 854 / 132 842 / 180 830 / 231 818 / 284
310
CFM / WATTS 817 / 74 805 / 119 793 / 166 781 / 215 769 / 265
290
CFM / WATTS 768 / 65 756 / 107 744 / 152 732 / 199 720 / 249
3.0
(a)
450
CFM / WATTS 1342 / 266 1330 / 333 1318 / 402 1306 / 472 1294 / 543
420
CFM / WATTS 1265 / 225 1253 / 289 1241 / 354 1229 / 421 1217 / 489
400
CFM / WATTS 1213 / 200 1201 / 262 1188 / 325 1176 / 389 1164 / 455
370
CFM / WATTS 1132 / 167 1120 / 224 1108 / 284 1096 / 345 1084 / 408
350
CFM / WATTS 1078 / 146 1066 / 202 1054 / 259 1042 / 318 1030 / 379
330
CFM / WATTS 1023 / 128 1011 / 181 999 / 236 986 / 293 974 / 351
310
CFM / WATTS 966 / 111 954 / 162 942 / 214 930 / 269 918 / 325
290
CFM / WATTS 909 / 96 897 / 144 885 / 195 873 / 247 861 / 301
