18
L8V1-SVX001-1A-EN
Table 8. L8V1B080U4VS Cooling Airflow (continued)
L8V1B080U4VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter
4.0
(a)
450
CFM / WATTS 1779 / 513 1779 / 607 1788 / 698 1807 / 788 1839 / 877
420
CFM / WATTS 1665 / 427 1661 / 514 1666 / 600 1683 / 685 1712 / 769
400
CFM / WATTS 1589 / 375 1584 / 459 1587 / 541 1600 / 622 1623 / 702
370
CFM / WATTS 1474 / 305 1465 / 383 1466 / 460 1475 / 536 1495 / 611
350
CFM / WATTS 1397 / 264 1388 / 339 1384 / 411 1392 / 484 1408 / 555
330
CFM / WATTS 1319 / 227 1310 / 298 1304 / 367 1308 / 435 1323 / 503
310
CFM / WATTS 1241 / 194 1232 / 261 1227 / 327 1226 / 391 1237 / 455
290
CFM / WATTS 1164 / 164 1155 / 227 1147 / 289 1144 / 350 1153 / 411
Table 9. L8V1C100U5VS Heating Airflow
L8V1C100U5VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure (iwc)
with Filter
Heating Capacity = 80,200
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating
Low
(a)
1500
CFM 1608 1624 1640 1656 1672
Temp. Rise
46 46 46 45 45
Watts 231 301 371 440 510
Medium Low 1600
CFM 1685 1701 1716 1732 1747
Temp. Rise
44 44 44 43 43
Watts 264 343 422 500 579
Medium 1900
CFM 2014 2021 2027 2033 2039
Temp. Rise
37 37 37 37 37
Watts 435 524 613 703 792
High
2000
CFM 2086 2085 2084 2083 2082
Temp. Rise
36 36 36 36 36
Watts 510 606 701 796 892
Table 10. L8V1C100U5VS Cooling Airflow
L8V1C100U5VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter
Outdoor
Tonnage - ODT
Airflow Setting
(CFM/Ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
2.5
450
CFM / WATTS 1107 / 105 1105 / 152 1101 / 205 1094 / 261 1085 / 321
420
CFM / WATTS 1033 / 88 1029 / 134 1023 / 184 1015 / 239 1004 / 297
400
CFM / WATTS 983 / 78 978 / 122 971 / 172 961 / 225 950 / 282
370
CFM / WATTS 909 / 65 901 / 107 892 / 155 880 / 206 866 / 262
350
CFM / WATTS 860 / 57 850 / 98 838 / 144 824 / 195 808 / 250
330
CFM / WATTS 810 / 50 797 / 90 783 / 135 767 / 185 750 / 238
310
CFM / WATTS 760 / 44 744 / 82 728 / 126 710 / 175 691 / 228
290
CFM / WATTS 710 / 38 691 / 75 671 / 118 651 / 167 631 / 220
3.0
450
CFM / WATTS 1328 / 167 1328 / 221 1327 / 280 1324 / 342 1318 / 407
420
CFM / WATTS 1240 / 140 1239 / 191 1237 / 247 1233 / 307 1226 / 370
400
CFM / WATTS 1180 / 123 1180 / 173 1177 / 227 1172 / 286 1164 / 347
370
CFM / WATTS 1092 / 101 1090 / 148 1085 / 201 1079 / 257 1069 / 316
350
CFM / WATTS 1033 / 88 1029 / 134 1023 / 184 1015 / 239 1004 / 297
330
CFM / WATTS 973 / 76 968 / 120 961 / 170 951 / 223 938 / 279
310
CFM / WATTS 914 / 66 907 / 108 897 / 156 885 / 208 871 / 263
290
CFM / WATTS 855 / 56 844 / 97 832 / 143 818 / 194 803 / 248
3.5
450
CFM / WATTS 1550 / 253 1549 / 312 1548 / 377 1545 / 446 1540 / 517
420
CFM / WATTS 1447 / 210 1446 / 267 1445 / 328 1442 / 394 1437 / 462
400
CFM / WATTS 1378 / 184 1377 / 239 1377 / 299 1374 / 363 1368 / 429
370
CFM / WATTS 1274 / 150 1274 / 202 1272 / 259 1269 / 320 1262 / 384
350
CFM / WATTS 1205 / 130 1204 / 180 1202 / 235 1198 / 294 1190 / 356
330
CFM / WATTS 1136 / 112 1135 / 160 1131 / 214 1126 / 271 1117 / 331
310
CFM / WATTS 1067 / 95 1064 / 142 1060 / 194 1052 / 249 1042 / 307
290
CFM / WATTS 998 / 81 994 / 126 987 / 176 978 / 229 966 / 286
AAiirrffllooww TTaabblleess
