[ II Components and Functions ]
- 2 -
HWE1832A GB
II Components and Functions
[1] Components and Functions
1. Indoor (Main) Unit
(1) In case of rear inlet (2) In case of bottom inlet
Air inlet
Air outlet
Air outlet
Air inlet
