Trane Precedent FIADAST003 Series User Manual

12 ACC-SVN240A-EN
Installation
6. Secure the mounting bracket to divider with four screws holding the sensing tubes in place
against the fan wall as shown in the following figures.
Figure 10. For model: D cabinet (digit 39 = D), install sensing tube
Insert sensing tube through
knockout in divider
Remove rear
access panel
Remove supply
duct cover
Assemble sensing
tubes (three or four tubes)
secure with screws
Figure 11. For model: D cabinet (digit 39 = D) downflow installation
Sensing tubes
Mounting bracket
