8 ACC-SVN240A-EN
Installation
Figure 2. T/WS*150 downflow and horizontal
Module, indoor fan,
temperature sensing
Bracket,
DAS support
Tube, discharge
air sensing
Tube, discharge
air rotating
Tube, discharge
air rotating
Tube, discharge
air connecting
Tube,
discharge
air sensing, sampling
Bracket, discharge
air sensor, top
Bracket, discharge
air sensor, top
Tube, discharge
air sensing, convertible
Bracket,
DAS support
Insulation
Insulation
Tube, discharge
air sensing
Tube, discharge
air rotating
Tube,
discharge
air connecting
Tube,
discharge
air sensing, sampling
Downflow Horizontal
Figure 3. Discharge air temperature - downflow and horizontal - view 1
Figure 4. Discharge air temperature - downflow and horizontal - view 2
