Fig. 4.1
Table 4.1
Units: In. (mm)
Item
Model
A
In.
(mm)
B
In.
(mm)
C
In.
(mm)
D
In.
(mm)
E
In.
(mm)
F
In.
(mm)
G
In.
(mm)
H
In.
(mm)
I
In.
(mm)
J
In.
(mm)
4UXD2018A
37.2
(945)
24.3
(618)
29.1
(738)
35.1
(892)
40.8
(1037)
28.4
(721)
29.1
(738)
4.9
(125)
8.0
(203)
10.5
(266)
4UXD2024A
43.3
(1101)
20.4
(517)
32.3
(820)
45.6
(1159)
50.4
(1279)
22.0
(558)
39.4
(1002)
6.3
(160)
9.3
(235)
10.6
(268)
4UXD2030A
4UXD2036A
39.8
(1011)
29.4
(748)
32.3
(820)
43.9
(1115)
48.3
(1226)
30.5
(775)
38.5
(979)
6.3
(160)
9.1
(231)
11.4
(290)
4UXD2042A
4UXD2048A
46.3
(1177)
25.4
(646)
33.5
(852)
45.3
(1150)
52.8
(1340)
29.5
(750)
37.5
(953)
7.5
(190)
12.4
(316)
13.8
(350)
For the units: 48K
