4.1.4 Leveling
The water level test must be done after installing the indoor unit to make sure the unit is horizontal,
as shown below.
Fig. 4.7
4.2 Installation of the Outdoor Unit
WARNING
(1) Install the unit where it will not be tilted by more than 5°.
(2) If the location is subject to strong winds, the additional force must be accounted for and
the unit must be fixed securely to the base.
Fig. 4.8
4.2.1 Outdoor Unit Dimensions
