3 Preparation for Installation
3.1 Standard Accessory Parts
The standard accessory parts listed below are furnished and should be used as required.
Table 3.1
Indoor Unit Accessories
No. Name Appearance Q'ty Usage
1 Wired Controller
1 To control the indoor unit
2
Wireless
Controller
+ Batteries
To control the indoor unit
(Optional Accessory)
3 Hanger
or
4 To fix the indoor unit
4 Nut with Washer
8
To fix the hook on the
cabinet of the unit
5 Nut with Washer
4
To fix the hook on the
cabinet of the unit
6 Nut 4
To be used together with
the hanger bolt for
installing the unit
7 Washer
4
To be used together with
the hanger bolt for
installing the unit
8 Insulation
1 To insulate the gas pipe
9 Insulation
1
To insulate the liquid
pipe
10 Fastener
4 To fasten the sponge
11 Flare Nut 1 To connect liquid pipe
12 Flare Nut
1 To connect gas pipe
To Next Page
