Trane R Series User Manual

120 RLC-SVX07A-EN
Controls Interface
DIP Switch Settings
Compressor Overload DIP Switches
The settings for these switches are shown in Table 27.
IPC Address
The IPC address set the address for Inter-Processor Communications of the
Clear Language Display modules. The following is the IPC DIP switch settings
for the RTAA 70 – 125 modules.
Table 27 Compressor Overload DIP Switch Settings
RTWA (Std. Cond. Temp.) DIP Switch Settings RTWA (Std. Cond. Temp.) DIP Switch Settings
To n s VAC/Hz RLA C.T.*
Overload
Setting ** To n s VAC/Hz RLA C.T.*
Overload
Setting **
35 575/60 37 -09 01001/09 35 575/60 40 -09 01111/15
460/60 46 -09 11001/25 460/60 50 -10 00000/00
380/60 55 -10 01000/08 380/60 61 -10 10000/16
230/60 91 -01 11001/25 230/60 100 -01 11111/31
200/60 105 -02 00100/04 200/60 115 -02 01011/11
400/50 44 -09 10110/22 400/50 50 -10 00000/00
220/50 80 -01 01111/15 220/50 87 -01 10110/22
40 575/60 43 -09 10100/21 40 575/60 50 -10 00000/00
460/60 54 -10 00111/07 460/60 62 -10 10001/17
380/60 65 -10 10101/21 380/60 75 -01 01010/10
230/60 108 -02 00111/07 230/60 124 -02 10001/17
200/60 124 -02 10001/17 200/60 142 -02 11011/27
400/50 52 -10 00011/03 400/50 62 -10 10001/17
220/50 94 -01 11011/27 220/50 108 -02 00111/07
50 575/60 57 -10 01011/11 50 575/60 67 -01 00001/01
460/60 72 -01 00111/07 460/60 84 -01 10011/19
380/60 87 -01 10110/22 380/60 101 -02 00001/01
230/60 143 -03 00110/06 230/60 167 -03 10010/18
200/60 164 -03 10001/17 200/60 192 -03 11100/28
400/50 69 -01 00011/03 400/50 84 -01 10011/19
220/50 126 -02 10011/19 220/50 147 -03 01000/08
60 575/60 68 -01 00010/02 60 575/60 81 -01 10000/16
460/60 85 -01 10100/20 460/60 101 -02 00001/01
380/60 102 -02 00010/02 380/60 123 -02 10001/17
230/60 169 -03 11011/27 230/60 203 -04 01000/08
200/60 194 -04 10011/19 200/60 233 -04 10011/19
400/50 82 -01 10001/17 400/50 101 -02 00001/01
220/50 148 -03 01001/09 220/50 176 -03 10110/22
* The Current Transformer base part number is X13580253. The numbers in this column are suffixes to the base number.
** On the DIP switch, 1=ON, O=OFF. The decimal value should be set in the compressor overload setting menu of the UCM.
If the DIP switch value does not match the decimal value entered into the UCM, the related compressor(s) will continue to
run, but a diagnostic will be initiated, both settings will be ignored, and the UCM will use the lowest possible trip setting
value.
