RLC-SVX07A-EN 35
Installation - Mechanical
Figure 16 RTWA/RTUA – Evaporator Water Pressure Drop
RTWA/RTUA- Evaporator Water Pressure Drop
0
5
10
15
20
25
30
35
40
0 50 100 150 200 250 300 350 400 450 500
FLOW (GPM)
PRESSURE DROP (FT. OF H
2
0)
