22 RAU-SVX01B-E4
Table 9
RAU 500 R134a RAU 600 R134a
Outdoor Ambient Temperature (°C)
25°C 30°C 35°C 40°C 45°C 25°C 30°C 35°C 40°C 45°C
HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP
bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar
-14 °C 11.0 1.7 12.1 1.7 13.3 1.7 14.6 1.7 16.1 1.7 11.2 1.7 12.2 1.7 13.3 1.7 14.5 1.7 15.9 1.7
-12 °C 10.7 1.9 11.7 1.9 12.8 1.9 14.1 1.9 15.5 1.9 10.9 1.9 11.8 1.9 12.9 1.9 14.0 1.9 15.3 1.9
-10 °C 10.4 2.0 11.4 2.0 12.4 2.0 13.6 2.0 15.0 2.0 10.6 2.0 11.5 2.0 12.5 2.0 13.6 2.0 14.8 2.0
-8 °C 10.1 2.2 11.1 2.2 12.1 2.2 13.3 2.2 15.0 2.2 10.3 2.2 11.2 2.2 12.1 2.2 13.2 2.2 14.9 2.2
-6 °C 9.9 2.3 10.8 2.3 11.9 2.3 13.5 2.3 15.2 2.3 10.1 2.3 10.9 2.3 11.9 2.3 13.4 2.3 15.1 2.3
-4 °C 9.8 2.5 10.7 2.5 12.1 2.5 13.7 2.5 15.5 2.5 9.9 2.5 10.7 2.5 12.0 2.5 13.6 2.5 15.3 2.5
-2 °C 9.7 2.7 10.9 2.7 12.3 2.7 13.9 2.7 15.7 2.7 9.8 2.7 10.8 2.7 12.2 2.7 13.8 2.7 15.6 2.7
0 °C 9.7 2.9 11.1 2.9 12.6 2.9 14.2 2.9 16.0 2.9 9.7 2.9 11.0 2.9 12.4 2.9 14.1 2.9 15.8 2.9
2 °C 10.0 3.2 11.3 3.2 12.8 3.2 14.4 3.2 16.2 3.2 9.9 3.2 11.2 3.2 12.7 3.2 14.3 3.2 16.1 3.2
4 °C 10.2 3.4 11.5 3.4 13.0 3.4 14.7 3.4 16.5 3.4 10.1 3.4 11.4 3.4 12.9 3.4 14.6 3.4 16.4 3.4
6 °C 10.4 3.6 11.8 3.6 13.3 3.6 15.0 3.6 16.8 3.6 10.3 3.6 11.7 3.6 13.2 3.6 14.9 3.6 16.7 3.6
8 °C 10.7 3.9 12.1 3.9 13.6 3.9 15.3 3.9 17.1 3.9 10.6 3.9 12.0 3.9 13.5 3.9 15.2 3.9 17.0 3.9
10 °C 10.9 4.2 12.3 4.2 13.9 4.2 15.6 4.2 17.4 4.2 10.9 4.2 12.3 4.2 13.8 4.2 15.5 4.2 17.3 4.2
Saturated suction
temperature.
Table 10
RAU 700 R134a RAU 800 R134a
Outdoor Ambient Temperature (°C)
25°C 30°C 35°C 40°C 45°C 25°C 30°C 35°C 40°C 45°C
HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP
bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar
-14 °C 11.1 1.7 12.0 1.7 13.1 1.7 14.3 1.7 15.6 1.7 11.2 1.7 12.2 1.7 13.3 1.7 14.5 1.7 15.8 1.7
-12 °C 10.7 1.9 11.6 1.9 12.6 1.9 13.8 1.9 15.0 1.9 10.9 1.9 11.8 1.9 12.8 1.9 14.0 1.9 15.2 1.9
-10 °C 10.4 2.0 11.2 2.0 12.2 2.0 13.3 2.0 14.5 2.0 10.5 2.0 11.4 2.0 12.4 2.0 13.5 2.0 14.7 2.0
-8 °C 10.1 2.2 10.9 2.2 11.9 2.2 12.9 2.2 14.4 2.2 10.3 2.2 11.1 2.2 12.1 2.2 13.1 2.2 14.8 2.2
-6 °C 9.9 2.3 10.7 2.3 11.6 2.3 12.9 2.3 14.6 2.3 10.0 2.3 10.9 2.3 11.8 2.3 13.2 2.3 15.0 2.3
-4 °C 9.7 2.5 10.5 2.5 11.5 2.5 13.0 2.5 14.7 2.5 9.9 2.5 10.7 2.5 11.9 2.5 13.4 2.5 15.1 2.5
-2 °C 9.5 2.7 10.3 2.7 11.7 2.7 13.2 2.7 14.9 2.7 9.7 2.7 10.6 2.7 12.0 2.7 13.6 2.7 15.4 2.7
0 °C 9.4 2.9 10.5 2.9 11.9 2.9 13.4 2.9 15.1 2.9 9.6 2.9 10.8 2.9 12.3 2.9 13.8 2.9 15.6 2.9
2 °C 9.4 3.2 10.6 3.2 12.1 3.2 13.6 3.2 15.3 3.2 9.7 3.2 11.0 3.2 12.5 3.2 14.1 3.2 15.8 3.2
4 °C 9.5 3.4 10.8 3.4 12.3 3.4 13.8 3.4 15.5 3.4 9.9 3.4 11.2 3.4 12.7 3.4 14.3 3.4 16.0 3.4
6 °C 9.7 3.6 11.0 3.6 12.5 3.6 14.0 3.6 15.8 3.6 10.1 3.6 11.5 3.6 12.9 3.6 14.5 3.6 16.3 3.6
8 °C 9.9 3.9 11.2 3.9 12.7 3.9 14.3 3.9 16.0 3.9 10.4 3.9 11.7 3.9 13.2 3.9 14.8 3.9 16.6 3.9
10 °C 10.1 4.2 11.4 4.2 12.9 4.2 14.5 4.2 16.3 4.2 10.6 4.2 12.0 4.2 13.4 4.2 15.1 4.2 16.8 4.2
Saturated suction
temperature.
