Trane RAU-SVX01B-E4 - Page 24

24 RAU-SVX01B-E4
Table 12
RAU 190 R407C RAU 260 R407C
Outdoor Ambient Temperature (°C)
25°C 30°C 35°C 40°C 45°C 25°C 30°C 35°C 40°C 45°C
HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP
bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar
-14 °C 14.0 2.7 15.9 2.7 18.1 2.7 15.0 2.7 17.0 2.7 19.4 2.7
-12 °C 14.2 3.0 16.1 3.0 18.3 3.0 20.7 3.0 15.3 3.0 17.4 3.0 19.7 3.0
-10 °C 14.4 3.2 16.3 3.2 18.5 3.2 20.9 3.2 15.6 3.2 17.7 3.2 20.0 3.2
-8 °C 14.6 3.4 16.6 3.4 18.8 3.4 21.2 3.4 15.9 3.4 18.0 3.4 20.4 3.4 23.0 3.4
-6 °C 14.9 3.7 16.9 3.7 19.1 3.7 21.5 3.7 24.2 3.7 16.3 3.7 18.4 3.7 20.8 3.7 23.4 3.7
-4 °C 15.1 4.0 17.1 4.0 19.3 4.0 21.8 4.0 24.5 4.0 16.6 4.0 18.8 4.0 21.2 4.0 23.9 4.0
-2 °C 15.4 4.3 17.4 4.3 19.7 4.3 22.1 4.3 24.8 4.3 17.0 4.3 19.2 4.3 21.7 4.3 24.3 4.3
0 °C 15.7 4.6 17.8 4.6 20.0 4.6 22.5 4.6 25.1 4.6 17.4 4.6 19.7 4.6 22.1 4.6 24.8 4.6 27.7 4.6
2 °C 16.0 4.9 18.1 4.9 20.3 4.9 22.8 4.9 25.5 4.9 17.9 4.9 20.1 4.9 22.6 4.9 25.3 4.9 28.3 4.9
4 °C 16.4 5.3 18.4 5.3 20.7 5.3 23.2 5.3 25.9 5.3 18.3 5.3 20.6 5.3 23.1 5.3 25.8 5.3 28.8 5.3
6 °C 16.7 5.7 18.8 5.7 21.1 5.7 23.6 5.7 26.3 5.7 18.8 5.7 21.1 5.7 23.6 5.7 26.4 5.7 29.3 5.7
8 °C 17.1 6.0 19.2 6.0 21.5 6.0 24.0 6.0 26.7 6.0 19.3 6.0 21.6 6.0 24.2 6.0 26.9 6.0 29.9 6.0
10 °C 17.5 6.4 19.6 6.4 21.9 6.4 24.5 6.4 27.2 6.4 19.8 6.4 22.2 6.4 24.7 6.4 27.5 6.4 30.5 6.4
Dew Temperature
At Evaporating
Pressure
Table 13
RAU 300 R407C RAU 350 R407C
Outdoor Ambient Temperature (°C)
25°C 30°C 35°C 40°C 45°C 25°C 30°C 35°C 40°C 45°C
HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP
bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar
-14 °C 14.8 2.7 16.8 2.7 19.1 2.7 14.2 2.7 15.6 2.7 17.2 2.7
-12 °C 15.0 3.0 17.1 3.0 19.4 3.0 13.7 3.0 15.0 3.0 16.6 3.0 18.3 3.0
-10 °C 15.3 3.2 17.4 3.2 19.8 3.2 22.4 3.2 13.2 3.2 14.5 3.2 16.0 3.2 17.6 3.2
-8 °C 15.7 3.4 17.8 3.4 20.2 3.4 22.8 3.4 12.9 3.4 14.1 3.4 15.5 3.4 17.1 3.4
-6 °C 16.0 3.7 18.2 3.7 20.5 3.7 23.2 3.7 12.6 3.7 13.7 3.7 15.1 3.7 16.6 3.7 18.2 3.7
-4 °C 16.4 4.0 18.6 4.0 21.0 4.0 23.6 4.0 26.5 4.0 12.3 4.0 13.4 4.0 14.7 4.0 16.1 4.0 17.7 4.0
-2 °C 16.8 4.3 19.0 4.3 21.4 4.3 24.0 4.3 27.0 4.3 12.1 4.3 13.2 4.3 14.4 4.3 15.8 4.3 17.3 4.3
0 °C 17.2 4.6 19.4 4.6 21.8 4.6 24.5 4.6 27.4 4.6 11.9 4.6 13.0 4.6 14.2 4.6 15.4 4.6 16.9 4.6
2 °C 17.6 4.9 19.9 4.9 22.3 4.9 25.0 4.9 28.0 4.9 11.8 4.9 12.8 4.9 13.9 4.9 15.2 4.9 16.6 4.9
4 °C 18.1 5.3 20.4 5.3 22.8 5.3 25.5 5.3 28.5 5.3 11.7 5.3 12.7 5.3 13.8 5.3 15.0 5.3 16.3 5.3
6 °C 18.6 5.7 20.9 5.7 23.4 5.7 26.1 5.7 29.1 5.7 11.7 5.7 12.6 5.7 13.7 5.7 14.8 5.7 16.0 5.7
8 °C 19.1 6.0 21.4 6.0 23.9 6.0 26.7 6.0 29.6 6.0 11.6 6.0 12.6 6.0 13.6 6.0 14.7 6.0 15.9 6.0
10 °C 19.6 6.4 22.0 6.4 24.5 6.4 27.3 6.4 30.3 6.4 11.6 6.4 12.5 6.4 13.5 6.4 14.6 6.4 15.7 6.4
Dew Temperature
At Evaporating
Pressure
Table 14
RAU 400 R407C RAU 450 R407C
Outdoor Ambient Temperature (°C)
25°C 30°C 35°C 40°C 45°C 25°C 30°C 35°C 40°C 45°C
HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP HP LP
bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar bar
-14 °C 14.5 2.7 16.0 2.7 18.1 2.7 14.5 2.7 16.0 2.7 17.7 2.7
-12 °C 14.2 3.0 16.2 3.0 18.4 3.0 14.0 3.0 15.4 3.0 17.0 3.0
-10 °C 14.4 3.2 16.4 3.2 18.6 3.2 21.1 3.2 13.6 3.2 14.9 3.2 16.5 3.2 18.2 3.2
-8 °C 14.7 3.4 16.7 3.4 18.9 3.4 21.4 3.4 13.2 3.4 14.5 3.4 16.0 3.4 17.6 3.4
-6 °C 15.0 3.7 17.0 3.7 19.2 3.7 21.7 3.7 12.9 3.7 14.2 3.7 15.6 3.7 17.1 3.7
-4 °C 15.2 4.0 17.3 4.0 19.6 4.0 22.0 4.0 12.7 4.0 13.9 4.0 15.2 4.0 16.7 4.0
-2 °C 15.5 4.3 17.6 4.3 19.9 4.3 22.4 4.3 25.1 4.3 12.5 4.3 13.7 4.3 14.9 4.3 16.3 4.3 17.9 4.3
0 °C 15.9 4.6 18.0 4.6 20.3 4.6 22.8 4.6 25.5 4.6 12.4 4.6 13.5 4.6 14.7 4.6 16.0 4.6 17.6 4.6
2 °C 16.2 4.9 18.3 4.9 20.6 4.9 23.2 4.9 25.9 4.9 12.3 4.9 13.3 4.9 14.5 4.9 15.8 4.9 17.2 4.9
4 °C 16.6 5.3 18.7 5.3 21.0 5.3 23.6 5.3 26.4 5.3 12.2 5.3 13.2 5.3 14.3 5.3 15.6 5.3 17.0 5.3
6 °C 16.9 5.7 19.1 5.7 21.4 5.7 24.0 5.7 26.8 5.7 12.1 5.7 13.1 5.7 14.2 5.7 15.4 5.7 16.7 5.7
8 °C 17.3 6.0 19.5 6.0 21.9 6.0 24.5 6.0 27.3 6.0 12.1 6.0 13.1 6.0 14.2 6.0 15.3 6.0 16.6 6.0
10 °C 17.8 6.4 20.0 6.4 22.4 6.4 25.0 6.4 27.8 6.4 12.1 6.4 13.1 6.4 14.1 6.4 15.2 6.4 16.4 6.4
Dew Temperature
At Evaporating
Pressure
