SS-SVX09A-EN 105
Service & Maintenance
Table 19. Compressor Circuit Breaker Data
Voltage Comp RLA LRA Must Must
Tons Hold Trip
200 9 41.4 269.0 50.4 58.0
230 9 41.4 251.0 50.4 58.0
460 9 18.1 117.0 22.0 25.3
575 9 14.4 94.0 17.5 20.2
380/415 9 17.2 110.0 20.9 24.1
200 14 60.5 404.0 73.7 84.7
230 14 60.5 376.0 73.7 84.7
460 14 26.3 178.0 32.0 36.8
575 14 21.0 143.0 25.6 29.4
380/415 14 26.2 174.0 31.9 36.7
Figure 53. Suction Line Filter/Drier Installation
