124
SS-SVX11K-EN
Table 43. Compressor circuit breakers (200-230 volts) (continued)
Must Hold
Must Trip
Unit
Voltage
1A / 2A 1B / 2B 1C / 2C 1A / 2A 1B / 2B 1C / 2C
50 Ton
200 57.1 63.1 - 65.7 72.5 -
230 51.4 57.1 - 59.2 65.7 -
60 Ton
200 69.3 69.3 - 79.7 79.7 -
230 59.4 59.4 - 68.3 68.3 -
80 Ton
200 73.7 73.7 73.7 84.7 84.7 84.7
230 63.1 63.1 63.1 72.5 72.5 72.5
100 Ton
200 73.7 73.7 105.2 84.7 84.7 121
230 63.1 63.1 90.7 72.5 72.5 104.3
120 Ton
200 105 105.2 105.2 121 121 121
230 90.7 90.7 90.7 104.3 104.3 104.3
Table 44. Compressor circuit breakers (460-575 volts)
Dial Setting
Unit
Voltage
1A / 2A 1B / 2B 1C / 2C
20 Ton
460 20.8 20.8 -
575 17.7 17.7 -
25 Ton
460 20.8 24.9 -
575 17.7 21.4 -
30 Ton
460 28.5 28.5 -
575 25.9 25.9 -
40 Ton
460 20.8 20.8 -
575 17.7 17.7 -
50 Ton
460 22.6 24.9 -
575 19.1 21.4 -
60 Ton
460 28.5 28.5 -
575 25.9 25.9 -
80 Ton
460 28.4 28.4 28.4
575 22.7 22.7 22.7
100 Ton
460 28.4 28.4 41.6
575 22.7 22.7 33.3
120 Ton
460 41.6 41.6 41.6
575 33.3 33.3 33.3
MMaaiinntteennaannccee
