8 RRU-SVX02F-EN
Model Number Descriptions
DIGIT 1, 2, 3 — UNIT TYPE
RRU
DIGIT 4, 5 — COOLING
CAPACITY
12 = 12.5 Tons
15 = 15 Tons
17 = 17.5 Tons
20 = 20 Tons
25 = 25 Tons
DIGIT 6— CABINET DESIGN
H = High Efficiency
DIGIT 7— MAJOR DESIGN
SEQUENCE
G
DIGIT 8— UNIT VOLTAGE
3 = 208/230
4 = 460
5 = 575
DIGIT 9— HEAT TYPE
N = Indirect Fired Heat
DIGIT 10 — RESERVED FOR
FUTURE USE
DIGIT 11 — MINOR DESIGN
SEQUENCE
B = 5 SCCR
C = 65 SCCR
DIGIT 12 — HEAT CAPACITY
DIGIT 13 — FUEL TYPE
1=Natural Gas
2=Propane
DIGIT 14 — CAPACITY
CONTROL
0=None
A= APR
DIGIT 15 — CONDENSER TYPE
0=Air Cooled
1=Water Cooled
DIGIT 16 — DRAIN PAN
0=None
A= Drain Pan
B = S/S Drain Pan
DIGIT 17 — INTAKE DESIGN
0=Standard
1 = Elevated Snow Design
DIGIT 18 — RESERVED FOR
FUTURE USE
DIGIT 19 — CONTROLS
0 = No Controls
A = Non - DDC Controls
B = 4.8aL - MP581 with Display
E = 4.8aL_2stage_ER - MP581 with
Display
F = 4.8aL_3stage_ER - MP581 with
Display
G = 4.9.1L - MP581 with Display
H = 4.8aL - UC600 with Display
J = 4.8aL - MP581 without Display
M = 4.8aL_2stage_ER - MP581
without Display
N = 4.8aL_3stage_ER - MP581
without Display
P = 4.9.1L - MP581 without Display
Q = 4.9.1L- UC600 with Display
R = 4.8aL - UC600 without Display
S = 5.3L-MP581 with Display
T = 5.3- UC600 with Display
U = 5.3L- MP581 without Display
V = 5.3L- UC600 without Display
W = Custom Controller
DIGIT 20 — DP SWITCH
0=None
1 = DP Switch
DIGIT 21 — DAMPER OPTIONS
0 = No Return Air Damper
B = Outdoor Air Low Leak Damper -
Title 24
DIGIT 22 — DRIVE SELECTION
0 = Factory Installed
1 = Low Static Drive
2 = Low Static Drive with Motor
3 = Pulley Mod
DIGIT 23 — MOTOR DRIVE
0 = Factory Installed
A = Belt Drive with VFD
B = Belt Drive with VFD and
Oversized Motor
DIGIT 24 — BIRD SCREEN
0=None
1 = Bird Screen
2 = Filter Screen
DIGIT 25 — REMOTE PANEL
0=None
A = Terminal Strip without Remote
Panel
B = Terminal Strip with Remote
Panel
IF DF ER
0N/A N/A
A 250 6-inch Precedent
B 350 12-inch Voyager 2 STAGE
C 400 18-inch 3 STAGE
