Trane RT-SVX19A-E4 - Page 28

Installation
RT-SVX19A-E428
Table 22 - Electrical data - TKD/TKH Compressor motor and condenser motor
(1) At Eurovent rating conditions : Indoor return Air (27°C DB / 19°C WB) - Ambiant 35°C
(2) per motor
Table 23 - Electrical data - YKD/YKH Compressor motor and condenser motor
(1) At Eurovent rating conditions : Indoor return Air (27°C DB / 19°C WB) - Ambiant 35°C
(2) per motor
TKD/H TKD/H TKD/H TKD/H
155 175 200 250
Compressor
Number 2 2 2 2
Type Scroll Scroll Scroll Scroll
Model 9T / 5T 10T / 6.7T 9T / 9T 10T / 10T
Rated Amps (1) (A) 15.0 / 8.5 15.1 / 11.4 14.7 / 14.7 15.3 / 15.3
Locked rotor Amps (2) (A) 118 / 65.5 118 / 101 118 / 118 118 / 118
Outdoor Fan
Nominal Airflow (m
3
/h) 15350 19750 21000 23500
Type Axial Axial Axial Axial
Diameter (mm) 660 660 710 710
Drive type Direct Direct Direct Direct
Number 2 2 2 2
Motor HP (kW) 0.25 0.25 0.56 0.56
Motor Rated Amps (1) (A) 1. 6 1. 6 2.3 2.3
Motor Locked rotor Amps (2) (A) 3.8 3.8 5.8 5.8
Motor RPM (rpm) 925 925 925 925
YKD/H YKD/H YKD/H YKD/H
155 175 200 250
Compressor
Number 2 2 2 2
Type Scroll Scroll Scroll Scroll
Model 9T / 5T 10T / 6.7T 9T / 9T 10T / 10T
Nominal Amps (1) (A) 15.0 / 8.5 15.1 / 11.4 14.7 / 14.7 15.3 / 15.3
Locked rotor Amps (2) (A) 118 / 65.5 118 / 101 118 / 118 118 / 118
Outdoor Fan
Nominal Airflow (m
3
/h) 15350 19750 21000 23500
Type Axial Axial Axial Axial
Diameter (mm) 660 660 710 710
Drive type Direct Direct Direct Direct
Number / Voltage 2 2 2 2
Motor HP (kW) 0.25 0.25 0.56 0.56
Motor Rated Amps (1) (A) 1. 6 1. 6 2.3 2.3
Motor Locked rotor Amps (2) (A) 3.8 3.8 5.8 5.8
Motor RPM (rpm) 925 925 925 925
