Controls Interface
Each compressor has its own screen depending on which radio key is pressed.
When toggling between compressor screens, say to compare starts and run time,
the same lines can be seen without additional key strokes. For example, toggling
from the bottom of the compressor 1A menu accesses the top of the compressor
2A menu.
Refrigerant Screen
The refrigerant screen displays those aspects of the chiller related to the refrigerant
circuits.
Tab. VI-02 - Compressor Screen
Description Resolution Units
Amps L1 L2 L3 XXX Amps
% RLA L1 L2 L3 X.X % RLA
Unit Volts XXX Volts
Oil Temperature X.X F / C
Intermediate Oil Pressure X.X Pressure
Suction Pressure X.X Pressure
Starts/ Run Hours X, XX:XX hr:min
