RTAC-SVX002A-EN 88
Diagnostics
Hex
Code
Diagnostic Name and
Source
Severity Persistence Criteria Reset Level
199 Low Oil Flow – Compressor
1B
Immediate Latch Same as Low Oil Flow - Compressor 1A Local
19A Low Oil Flow – Compressor
2A
Immediate Latch Same as Low Oil Flow - Compressor 1A Local
19B Low Oil Flow – Compressor Immediate
2B
Latch Same as Low Oil Flow - Compressor 1A Local
B5 Low Suction Refrigerant
Pressure - Circuit 1
Immediate Latch a. The Suction Refrigerant Pressure (or either of the compressor
suction pressures) dropped below 10 Psia just prior to compressor
start (after EXV preposition). b. The pressure fell below 16 Psia while
running after the ignore time had expired, or fell below 10 Psia (or 5
Psia in software prior to Oct'02) before the ignore time had expired.
The ignore time is function of outdoor air temperature. Note: Part b. is
identical to Low Evaporator Refrigerant Temperature diagnostic except
for the trip integral and trip point settings.
Local
B6 Low Suction Refrigerant
Pressure - Circuit 2
Immediate Latch Same as Low Suction Refrigerant Pressure - Circuit 1 Local
B7 Low Suction Refrigerant
Pressure - Cprsr 1B
Immediate Latch Same as Low Suction Refrigerant Pressure - Circuit 1 Local
B8 Low Suction Refrigerant
Pressure - Cprsr 2B
Immediate Latch Same as Low Suction Refrigerant Pressure - Circuit 1 Local
BA Motor Current Overload –
Compressor 1A
Immediate Latch Compressor current exceeded overload time vs. trip characteristic.
For A/C products Must trip = 140% RLA, Must hold=125%, nominal
trip 132.5% in 30 seconds
Local
BB Motor Current Overload –
Compressor 1B
Immediate Latch Same as Motor Current Overload - Compressor 1A Local
BC Motor Current Overload –
Compressor 2A
Immediate Latch Same as Motor Current Overload - Compressor 1A Local
BD Motor Current Overload –
Compressor 2B
Immediate Latch Same as Motor Current Overload - Compressor 1A Local
1AD MP Application Memory CRC
Error
Immediate Latch Memory error criteria TBD Remote
6A1 MP: Could not Store Starts
and Hours
Info Latch MP has determined there was an error with the previous power down
store. Starts and Hours may have been lost for the last 24 hours.
Remote
5FF MP: Invalid Conguration Immediate Latch MP has an invalid conguration based on the current software
installed
Remote
6A2 MP: Non-Volatile Block Test
Error
Info Latch MP has determined there was an error with a block in the Non-Volatile
memory. Check settings.
Remote
69C MP: Non-Volatile Memory
Reformat
Info Latch MP has determined there was an error in a sector of the Non-Volatile
memory and it was reformatted. Check settings.
Remote
D9 MP: Reset Has Occurred Info NonLatch The main processor has successfully come out of a reset and built
its application. A reset may have been due to a power up, installing
new software or conguration. This diagnostic is immediately and
automatically cleared and thus can only be seen in the Historic
Diagnostic List in TechView
Remote
1E1 Oil Flow Fault – Compressor
1A
Immediate Latch The Intermediate Oil Pressure Transducer for this cprsr is reading a
pressure either above its respective circuit's Condenser Pressure by
15 Psia or more, , or below its respective Suction Pressure 10 Psia or
more for 30 seconds continuously.
Local
1E2 Oil Flow Fault – Compressor
1B
Immediate Latch Same as Oil Flow Fault - Compressor 1A Local
5A0 Oil Flow Fault – Compressor
2A
Immediate Latch Same as Oil Flow Fault - Compressor 1A Local
5A1 Oil Flow Fault – Compressor
2B
Immediate Latch Same as Oil Flow Fault - Compressor 1A Local
1E6 Oil Temperature Sensor –
Cprsr 1B
Normal Latch Bad Sensor or LLID Remote
1E8 Oil Temperature Sensor –
Cprsr 2B
Normal Latch Bad Sensor or LLID Remote
1E6 Oil Temperature Sensor –
Cprsr 1A
Normal Latch Bad Sensor or LLID Remote
1E8 Oil Temperature Sensor –
Cprsr 2B
Normal Latch Bad Sensor or LLID Remote
