37
RLC-SVX02G-E4
Installation - Mechanical
0 -2.2 0.0 -2.2 0.0
1 -2.4 -0.2 -2.4 -0.2
2 -2.8 -0.6 -2.8 -0.6
3 -3.2 -0.9 -3.1 -0.9
4 -3.5 -1.3 -3.4 -1.2
5 -3.9 -1.7 -3.7 -1.5
6 -4.3 -2.1 -4.1 -1.8
7 -4.7 -2.4 -4.4 -2.2
8 -5.1 -2.8 -4.7 -2.4
9 -5.4 -3.2 -5.0 -2.8
10 -5.8 -3.6 -5.3 -3.1
11 -6.3 -4.1 -5.7 -3.5
12 -6.7 -4.5 -6.1 -3.8
13 -7.2 -4.9 -6.4 -4.2
14 -7.6 -5.4 -6.8 -4.6
15 -8.1 -5.8 -7.2 -4.9
16 -8.6 -6.3 -7.6 -5.3
17 -9.1 -6.8 -8.0 -5.8
18 -9.6 -7.4 -8.4 -6.2
19 -10.1 -7.9 -8.8 -6.6
20 -10.7 -8.4 -9.3 -7.1
21 -11.2 -9.0 -9.8 -7.6
22 -11.8 -9.6 -10.2 -8.0
23 -12.4 -10.2 -10.7 -8.5
24 -13.1 -10.8 -11.3 -9.1
25 -13.7 -11.4 -11.8 -9.6
26 -14.3 -12.1 -12.3 -10.1
27 -15.0 -12.8 -12.9 -10.7
28 -15.7 -13.5 -13.6 -11.3
29 -16.4 -14.2 -14.2 -11.9
30 -17.2 -14.9 -14.8 -12.6
31 -17.9 -15.7 -15.5 -13.3
32 -18.7 -16.5 -16.2 -14.0
33 -19.6 -17.3 -16.9 -14.7
34 -20.4 -18.2 -17.7 -15.5
35 -20.6 -19.1 -18.5 -16.3
36 -20.6 -19.9 -19.3 -17.1
37 -20.6 -20.9 -20.2 -17.9
38 -20.6 -21.8 -20.6 -18.8
39 -20.6 -22.8 -20.6 -19.7
40 -20.6 -23.8 -20.6 -20.7
41 -20.6 -24.8 -20.6 -21.6
42 -20.6 -25.9 -20.6 -22.7
43 -20.6 -27.0 -20.6 -23.7
44 -20.6 -28.1 -20.6 -24.8
45 -20.6 -29.3 -20.6 -25.9
46 -20.6 -30.5 -20.6 -27.1
47 -20.6 -31.7 -20.6 -28.3
48 -20.6 -32.9 -20.6 -29.5
49 -20.6 -34.3 -20.6 -30.8
50 -20.6 -35.6 -20.6 -32.1
51 -20.6 -36.9 -20.6 -33.5
52 -20.6 -38.4 -20.6 -34.9
53 -20.6 -39.8 -20.6 -36.3
54 -20.6 -41.3 -20.6 -37.8
See notes for Chart 3 on following page.
Important! Concentration is based on weight percentage.
Chart 3 – Recommended Low Evaporator Refrigerant Cutout (LRTC) and % Glycol for
RTAC Chillers
Ethylene Glycol
Propylene Glycol
%
Glycol
Low Refrigerant
Temperature
Cutout °C
Solution
Freeze
Point °C
Low Refrigerant
Temperature
Cutout °C
Solution
Freeze
Point °C
To Next Page
