Wire Sizing
Unit without
Disconnect Switch
Unit with
Disconnect Switch
Wire Selection Size to
Main Terminal Block
Wire Selection Size to Disconnect Switch
Maximum cable
size mm²
Disconnect Switch
size (Amps)
Maximum cable
size mm
2
Unit
Size
Unit
Size
Table J-2 - Customer Wire Selection RTAC 230 - 400
Voltage
400/3/50
Standard
230 4x240 3x160A + 6x250A + 3x400A 6x240
240 4x240 3x160A + 6x250A + 3x400A 6x240
250 4x240 3x160A + 6x250A + 3x400A 6x240
275 4x240 3x160A + 6x250A + 3x400A 6x240
300 4x240 3x160A + 9x400A 6x240
350 4x240 3x160A + 12x250A 6x240
375 4x240 3x160A + 6x400A + 6x250A 6x240
400 4x240 3x160A + 12x400A 6x240
Standard Low Noise
230 4x240 3x160A + 6x250A + 3x400A 6x240
240 4x240 3x160A + 6x250A + 3x400A 6x240
250 4x240 3x160A + 6x250A + 3x400A 6x240
275 4x240 3x160A + 6x250A + 3x400A 6x240
300 4x240 3x160A + 9x400A 6x240
350 4x240 3x160A + 12x250A 6x240
375 4x240 3x160A + 6x400A + 6x250A 6x240
400 4x240 3x160A + 12x400A 6x240
High Efficiency
250 4x240 3x160A + 6x250A + 3x400A 6x240
275 4x240 3x160A + 6x250A + 3x400A 6x240
300 4x240 3x160A + 9x400A 6x240
350 4x240 3x160A + 12x250A 6x240
375 4x240 3x160A + 6x400A + 6x250A 6x240
400 4x240 3x160A + 12x400A 6x240
High Efficiency Low Noise
250 4x240 3x160A + 6x250A + 3x400A 6x240
275 4x240 3x160A + 6x250A + 3x400A 6x240
300 4x240 3x160A + 9x400A 6x240
350 4x240 3x160A + 12x250A 6x240
375 4x240 3x160A + 6x400A + 6x250A 6x240
400 4x240 3x160A + 12x400A 6x240
Extra Efficiency
255 4x240 3x160A + 6x250A + 3x400A 6x240
275 4x240 3x160A + 6x250A + 3x400A 6x240
300 4x240 3x160A + 9x400A 6x240
355 4x240 3x160A + 6x400A + 6x250A 6x240
375 4x240 3x160A + 6x400A + 6x250A 6x240
400 4x240 3x160A + 12x400A 6x240
Extra Efficiency Low Noise
255 4x240 3x160A + 6x250A + 3x400A 6x240
275 4x240 3x160A + 6x250A + 3x400A 6x240
300 4x240 3x160A + 9x400A 6x240
355 4x240 3x160A + 6x400A + 6x250A 6x240
375 4x240 3x160A + 6x400A + 6x250A 6x240
400 4x240 3x160A + 12x400A 6x240*
Note: the material for cables and busbar is copper.
* For RTAC size 400 reduced length, the maximum cable size is 4 x 240 mm²
