RLC-SVX02G-E4
18
General Data
SI Units
Table G-12 - General Data RTAC 255-400 Extra Efficiency Low Noise
Size 255 275 300 355 375 400
Cooling capacity (5) (6) kW 867.4 966.5 1090.3 1239.7 1334.3 1456.7
Power input (7) kW 292.1 324.3 363.4 418.8 455.4 495.5
Energy Efficiency Ratio (5) (6) (as Eurovent) kW/kW 2.97 2.98 3.00 2.96 2.93 2.94
ESEER (as Eurovent) kW/kW 4.03 4.38 4.42 4.48 4.6 4.57
IPLV (According to ARI conditions 44°F leaving water
temperature, 95°F entering air temperature) kW/kW 4.50 4.57 4.44 4.7 4.98 4.95
Compressor
Quantity 3 3 3 4 4 4
Nominal Size (1) tons 70-70/100 85-85/100 100-100/100 70-70/100-100 100-100/85-85 100-100/100-100
Evaporator
Evaporator Model EH300 EH320 EH321 EH440 EH480 EH480
Water Storage l 239 258 258 304 325 325
Minimum Flow l/s 22 24 24 27 29 29
Maximum Flow l/s 77 86 86 97 105 105
Number of water passes 2 2 2 2 2 2
Condenser
Quantity of Coils 4/4 4/4 4/4 4/4 4/4 4/4
Coil Length mm 4572/3658 5486/3658 6401/3658 6401/4572 6401/5486 6401/6401
Coil Height mm 1067 1067 1067 1067 1067 1067
Fin series fins/ft 180 180 180 180 180 180
Number of Rows 4 4 4 4 4 4
Condenser Fans
Quantity (1) 10/6 12/8 14/8 14/10 14/12 14/14
Diameter mm 762 762 762 762 762 762
Total Air Flow m3/s 51.54 61.05 67.17 73.31 79.41 85.53
Nominal RPM 680 680 680 680 680 680
Tip Speed m/s 27.5 27.5 27.5 27.5 27.5 27.5
Motor kW kW 0.75 0.75 0.75 0.75 0.75 0.75
Minimum Starting/Operating Ambient (2)
Standard Unit °C 0 0 0 0 0 0
Low-Ambient Unit °C -18 -18 -18 -18 -18 -18
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
Number of Independent
Refrigerant Circuits 2 2 2 2 2 2
% Minimum Load (3) 13 13 13 10 10 10
Operating Weight (4) kg 9540 10291 10964 11704 13233 14083
Shipping Weight (4) kg 9436 10168 10843 11713 13196 14029
Notes:
1. Data containing information on two circuits shown as follows: ckt1/ckt2
2. Minimum start-up/operation ambient based on a 2.22 m/s (5mph) wind across the condenser.
3. Percent minimum load is for total machine at 10°C (50°F) ambient and 7°C (44°F) leaving chilled water temperature, not each individual circuit.
4. With aluminium fins.
5. At Eurovent conditions, 7°C leaving water temperature and 35°C entering condenser air temperature.
6. Ratings based on sea level altitude and evaporator fouling factor of 0.017615 m²°K/kW
7. Unit kW input, including fans
