Trane RTAC 185 User Manual

45
RLC-SVX02G-E4
Electrical Data
Table E-2 - Electrical Data RTAC 120 - 200 Unit Wiring (400/3/50)
Motor Data
Compressor (Each)
Standard
High Efficiency Low Noise
120 1 312 346 797 0.89 200-200 35
130 1 345 390 927 0.89 200 -200 35
140 1 378 416 953 0.89 200-200 35
155 1 416 450 1055 0.89 315-250 35
170 1 454 479 1084 0.89 315-315 35
185 1 501 544 1279 0.89 315-315 35
200 1 548 580 1315 0.89 315-315 35
250 1 651 660 1395 0.89 250-250/315 35
275 1 727 718 1453 0.89 250-250/315 35
300 1 821 790 1525 0.89 315-315/315 35
350 1 908 829 1434 0.89 250-250/250-250 35
375 1 1002 930 1665 0.89 315-315/250-250 35
400 1 1096 1002 1737 0.89 315-315/315-315 35
Extra Efficiency
120 1 324 358 809 0.89 200-200 35
130 1 362 407 944 0.89 200 -200 35
140 1 393 431 968 0.89 200-200 35
155 1 436 470 1075 0.89 315-250 35
175 1 485 537 1272 0.89 315-250 35
185 1 524 567 1302 0.89 315-315 35
200 1 569 601 1336 0.89 315-315 35
255 1 675 684 1419 0.89 250-250/315 35
275 1 761 752 1487 0.89 250-250/315 35
300 1 858 827 1562 0.89 315-315/315 35
355 1 962 908 1643 0.89 315-315/250-250 35
375 1 1041 969 1704 0.89 315-315/250-250 35
400 1 1138 1044 1779 0.89 315-315/315-315 35
Extra Efficiency Low Noise
120 1 312 346 797 0.89 200-200 35
130 1 347 392 929 0.89 200 -200 35
140 1 378 416 953 0.89 200-200 35
155 1 418 452 1057 0.89 315-250 35
175 1 465 517 1252 0.89 315-250 35
185 1 503 546 1281 0.89 315-315 35
200 1 548 580 1315 0.89 315-315 35
255 1 651 660 1395 0.89 250-250/315 35
275 1 731 722 1457 0.89 250-250/315 35
300 1 825 794 1529 0.89 315-315/315 35
355 1 926 872 1607 0.89 315-315/250-250 35
375 1 1002 930 1665 0.89 315-315/250-250 35
400 1 1096 1002 1737 0.89 315-315/315-315 35
Unit
size
Number of Power
Connections
Maximum
Amps (1)
Starting
Amps (2)
Starting Amps (2) (7)
Direct on line start
Power
Factor (5)
Compressor
Fuse Size (A)
Short Circuit
Rating (kA)
