RLC-SVD05A-EN 15
Power SupplyPower Supply
There is a 3.0 amp fuse (X13110456020) on the power supply. If this fuse is open
LED 1 will not be on and there will not be any voltage out. This fuse can be
replaced. The fuse is a medium time delay 3.0 amp, 5X20mm.
Table 2. Output Voltage
Terminals Voltage
1+24VDC
2GND
3 COMM+
4 COMM-
