RTAD-SVX01F-E4 63
Installation - Electrical
User-defined configuration property types
UCPT_chiller_type
Structure definition
Item Type Bytes Range and meaning
Unsigned 8-bit (enum) 1 Range of enum values in
UCPT_chiller_type
Unit capacity SNVT_power_f 4 Capacity of unit (in watts)
Cooling type Unsigned 8-bit (enum) 1 0 = water-cooled 1 = air-
cooled 2-254 = unused
Number of circuits Unsigned 8-bit 1 0-2; number of circuits on
unit
Number of compressors on circuit 1 Unsigned 8-bit 1 0-3; number of
compressors on circuit 1
Number of compressors on circuit 2 Unsigned 8-bit 1 0-3; number of
compressors on circuit 2
Total length 9
Enumeration definitions for UCPT_chiller_type
Enumeration um n (Trane chiller
model designators)
0 RTA
1 CVH
2 CVG
3 CVR
4 CDH
5 RTH
6 CGW
7 CGA
8 CCA
9 RTW
10 RTX
11 RTU
12-254 Unused
255 Invalid (unknown)
UCPT_manufacturing_location
Range of enumeration values
Enumeration Enumeration definition
0 Field applied
(unknown location)
1 La Crosse, Wisconsin
2 Pueblo, Colorado
3 Charmes, France
4 Rushville, Indiana
5 Macon, Georgia
6 Waco, Texas
7 Lexington, Kentucky
8 Forsyth, Georgia
9 Clarksville, Tennessee
10 Ft. Smith, Arkansas
11 Penang, China
12 Colchester, UK
13 Curitiba, Brazil
14 Taicang, China
15 to 254 Unused
255 Invalid (unknown location)
Model information
(
See enumeration definitions
table below.
)
