Temperature Sensors
RTHC-SVD01B-EN 21
Table 3-4: Compressor Discharge Temperature Sensor
Actual
Te m p.
(F)
Actual
Resistance
(Ohms)
Thermistor
Voltage
(Volts DC)
Actual
Tem p.
(F)
Actual
Resistance
(Ohms)
Thermistor
Voltage
(Volts DC)
Actual
Te m p.
(F)
Actual
Resistance
(Ohms)
Thermistor
Voltage
(Volts DC)
75 10503 2.99 117 4006 1.81 159 1727 0.99
76 10248 2.96 118 3921 1.79 160 1695 0.97
77 10001 2.93 119 3838 1.76 161 1663 0.96
78 9760 2.90 120 3757 1.74 162 1633 0.94
79 9525 2.87 121 3679 1.72 163 1603 0.93
80 9298 2.84 122 3601 1.69 164 1573 0.92
81 9076 2.81 123 3527 1.67 165 1544 0.90
82 8861 2.78 124 3454 1.65 166 1516 0.89
83 8650 2.75 125 3383 1.62 167 1488 0.88
84 8446 2.72 126 3313 1.60 168 1461 0.86
85 8248 2.69 127 3245 1.58 169 1435 0.85
86 8054 2.66 128 3179 1.56 170 1409 0.84
87 7866 2.64 129 3115 1.53 171 1383 0.82
88 7683 2.61 130 3051 1.51 172 1359 0.81
89 7505 2.58 131 2990 1.49 173 1334 0.80
90 7330 2.55 132 2929 1.47 174 1310 0.79
91 7161 2.52 133 2870 1.45 175 1287 0.78
92 6997 2.49 134 2813 1.43 176 1264 0.76
93 6837 2.46 135 2756 1.41 177 1241 0.75
94 6680 2.43 136 2701 1.39 178 1220 0.74
95 6528 2.40 137 2648 1.37 179 1198 0.73
96 6380 2.37 138 2595 1.35 180 1177 0.72
97 6236 2.35 139 2544 1.33 181 1156 0.71
98 6095 2.32 140 2494 1.31 182 1136 0.70
99 5958 2.29 141 2445 1.29 183 1116 0.69
100 5824 2.26 142 2397 1.27 184 1097 0.68
101 5695 2.23 143 2350 1.25 185 1078 0.67
102 5568 2.21 144 2304 1.24 186 1059 0.66
103 5444 2.18 145 2260 1.22 187 1040 0.65
104 5323 2.15 146 2216 1.20 188 1023 0.64
105 5206 2.12 147 2173 1.18 189 1005 0.63
106 5092 2.10 148 2131 1.16 190 988 0.62
107 4980 2.07 149 2090 1.15 191 971 0.61
108 4871 2.04 150 2050 1.13 192 954 0.60
109 4765 2.02 151 2011 1.11 193 938 0.59
110 4662 1.99 152 1973 1.10 194 922 0.58
111 4561 1.97 153 1936 1.08 195 906 0.57
112 4463 1.94 154 1899 1.07 196 891 0.57
113 4367 1.91 155 1863 1.05 197 876 0.56
114 4273 1.89 156 1828 1.03 198 862 0.55
115 4182 1.86 157 1794 1.02 199 847 0.54
116 4092 1.84 158 1760 1.00 200 833 0.53
Notes:
1. Overall accuracy for the sensor is at least +1 over the range shown.
2. As you compare a thermistor resistance (or input voltage) reading with the “actual” temperature indicated by the
thermometer, be sure to consider the location and precision of the thermometer when you decide whether or not the
thermistor is out of specified accuracy.
3. The thermistor resistances given do not account for the self-heating effects that are present when connected to the UCM.
A connected “operating” thermistor will read a slightly lower (less than 1%) resistance.
