Current Transformer and Current Input
32 RTHC-SVD01B-EN
Table 4-3: Line Current vs. Current and Volts
Line Current
(%RLA)
Terminal Input
Current
(mA RMS)
Terminal Volts
(VAC RMS) (±5)
00 0
55 1.2
10 10 1.4
15 15 1.5
20 20 1.7
25 25 1.8
30 30 2.0
35 35 2.1
40 40 2.2
45 45 2.4
50 50 2.5
55 55 2.6
60 60 2.8
65 65 2.9
70 70 3.0
75 75 3.2
80 80 3.3
85 85 3.4
90 90 3.6
95 95 3.7
100 100 3.8
105 105 4.0
110 110 4.1
115 115 4.2
120 120 4.4
125 125 4.5
130 130 4.6
