Module Power and Miscellaneous I/O
RTHC-SVD01B-EN 85
.
Table 13-10: Input values for External Chilled Water Setpoints
Current (mA) Voltage (VDC)
Resulting Chilled
Water Setpt (F)
+
4F
4.0 2.0 0.0
5.2 2.6 5.0
6.5 3.2 10.0
7.7 3.9 15.0
8.9 4.5 20.0
10.2 5.1 25.0
11.4 5.7 30.0
12.6 6.3 35.0
13.8 6.9 40.0
15.1 7.6 45.0
16.3 8.2 50.0
17.5 8.8 55.0
18.8 9.4 60.0
20.0 10.0 65.0
Table 13-11: Input values for External Current Limit Setpoints
Input
Current
(mA)
Voltage
(VDC)
Resulting Current Limit
Setpt (%RLA) +
5%
4.0 2.0 40
6.0 3.0 50
8.0 4.0 60
10.0 5.0 70
12.0 6.0 80
14.0 7.0 90
16.0 8.0 100
18.0 9.0 110
20.0 10.0 120
