Troubleshooting
42 RLC-SVN005B-EN
Troubleshooting
Table 3. Troubleshooting chart
Description of the Problem Possible Causes
Chiller starts but only runs for a few seconds.
• Typically caused from a mis-wire of the low voltage.
Compressor starts immediately when power is applied.
• Start command of the Benshaw Redistart wired incorrectly directly to 120 Vdc.
Compressor starts, runs less than 10 seconds and
CH530 shuts down on a “Phase Reversal” diagnostic.
• CH530 not programmed correctly. Disable “Phase Reversal” in CH530 controller.
While chiller is in “Auto” mode and compressor is off
the shunt trip opens locking out compressor.
• Troubleshoot the Benshaw SSS using RTHD-SVD02*-EN. Possible problem with SCR.
Shunt trips opens on compressor start.
• P1 setting of Benshaw starter set incorrectly. Remove power to the unit and reprogram
all “P” parameters of the Benshaw starter.
(To program starter, apply external 120V to logic modules.)
(
• Faulty shunt trip.
See Troubleshooting guides RTHD-SVD02*-EN and RLC-SVD06*-EN for more information.
