Trane RTHD

RLC-SVD05A-EN 69
TechView Service Tool
Watch for the LED to light. Refer to Figure 43.
5 When the LED lights, remove the magnet and click on “Yes”. Refer to Ta ble 44
on page 69.
6 Confirm that binding took place. The red face should have turned green.
Figure 43.Panel and Frame Mounted LLIDs
Magnet
LED
Figure 44.Selecting a LLID to bind
