RLC-SVX14H-GB
11
General data
Table 2 - RTWD High Effi ciency - R134a (Continued)
RTWD RTWD RTWD RTWD RTWD RTWD RTWD
130 140 160 180 200 220 250
Indicative performances
Cooling Capacity (1) (kW) 488 531 579 638 700.1 765 836
Total Power input in cooling (1) (kW) 99 107 114 127 138.7 155 168
Heating Capacity (2) (kW) 512 562 616 677 740.1 812.9 888.4
Total Power input in heating (2) (kW) 116 128 139 154 167.9 184.6 199.6
Compressor
Compressor Number per Circuit # 1/1 1/1 1/1 1/1 1/1 1/1 1/1
Type Screw
Model M1/M1 M1/M2 M2/M2 M2/N1 N1/N1 N1/N2 N2/N2
Evaporator
Quantity # 1111111
Type Flooded shell and tube heat exchanger
Evaporator model E3AM3 E3AM2 E3AM1 E3AMJ E5AM2 E5AM1 E5AMJ
Evaporator Water Content volume (l) 72.6 77.0 85.0 91.0 108 113.3 120.3
Two pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 8.8 9.5 10.7 11.7 13.3 14.1 15.1
Evap. Water Flow rate - Maximum
(3)
(l/s) 32.4 34.9 39.1 43.0 48.6 51.5 55.3
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
Three pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 5.9 6.4 7.13 7.82 8.83 9.3 10.1
Evap. Water Flow rate - Maximum
(3)
(l/s) 21.6 23.3 26.12 28.64 32.43 34.3 36.9
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
DN150-6"
(168.3 mm)
DN150-6"
(168.3 mm)
DN150-6"
(168.3 mm)
DN150-6"
(168.3 mm)
DN150-6"
(168.3 mm)
DN150-6"
(168.3 mm)
DN150-6"
(168.3 mm)
Condenser
Quantity # 1111111
Type Shell and Tube Heat Exchanger
Condenser model C3AM3 C3AM2 C3AM1 C3AMJ C5AM2 C5AM2 C5AM1
Condenser Water Content volume (l) 81.7 86.8 93.0 99.0 118 117.8 133.3
Two pass condenser
Cond. Water Flow rate - Minimum (l/s) 10 11 12 13 15.4 15.4 18
Cond. Water Flow rate - Maximum (l/s) 37 40 44 48 56.4 56.4 65.9
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
Dimensions (4)
Unit Length (mm) 3400 3400 3400 3490 3490 3490 3490
Unit Width (mm) 1280 1280 1280 1310 1310 1310 1310
Unit Height (mm) 1950 1950 1950 1970 2010 2010 2010
Weights (5)
Shipping Weight (kg) 3616 3638 3668 3851 4262 4273 4326
Operating Weight (kg) 3771 3802 3846 4042 4488 4594 4579
System data (6)
Nb of refrigerant circuit # 2222222
Minimum cooling load % % 30 30 30 30 30 30 30
Standard unit
R134a refrigerant charge Circuit1 /
Circuit 2 (6)
(kg) 61/61 60/62 61/61 60/62 81/81 80/83 82/82
Oil charge Circuit1 / Circuit 2 (l) 9.9/9.9 9.9/9.9 10/10 10/12 12/12 11.7/11.7 11.7/11.7
POE Oil type OIL048E or OIL023E
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
