General data
Table 3 - RTWD Extra High Effi ciency - R134a
RTWD RTWD RTWD
160 180 200
Indicative performances
Cooling Capacity (1) (kW) 598 659 709
Total Power input in cooling (1) (kW) 114 126 136
Heating Capacity (2) (kW) 629 691 744
Total Power input in heating (2) (kW) 138 153 166
Compressor
Compressor Number per Circuit # 1/1 1/1 1/1
Type Screw
Model M2/M2 M2/N1 N1/N1
Evaporator
Quantity # 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model E4AM1 E4AMJ E5AMJ
Evaporator Water Content volume (l) 72.6 77.0 84.5
Two pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 11.7 12.7 15.1
Evap. Water Flow rate - Maximum (3) (l/s) 43.0 46.6 55.3
Nominal water connection size (Grooved coupling) (in) - (mm)
611
(168.3 mm)
611
(168.3 mm)
611
(168.3 mm)
Three pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 7.8 8.5 10.1
Evap. Water Flow rate - Maximum (3) (l/s) 28.6 31 36.9
Nominal water connection size (Grooved coupling) (in) - (mm)
411
(114.3 mm)
411
(114.3 mm)
411
(114.3 mm)
Condenser
Quantity # 1 1 1
Type Shell and Tube Heat Exchanger
Condenser model C4AM2 C4AMJ C5AMJ
Condenser Water Content volume (l)
Two pass condenser 113.4 130.6 148.2
Cond. Water Flow rate - Minimum (l/s) 12.9 15.4 20.5
Cond. Water Flow rate - Maximum (l/s) 47.5 56.4 75.1
Nominal water connection size (Grooved coupling) (in) - (mm) 6” (168.3) 6” (168.3) 6” (168.3)
Dimensions (4)
Unit Length (mm) 3830 3830 3490
Unit Width (mm) 1280 1310 1310
Unit Height (mm) 2010 2010 2010
Weights (5)
Shipping Weight (kg) 3954 4175 4357
Operating Weight (kg) 4172 4408 4625
System data (6)
Nb of refrigerant circuit # 2 2 2
Minimum cooling load % % 30 30 30
Standard unit
R134a refrigerant charge Circuit1 / Circuit 2 (6) (kg) 80/80 79/81 80/79
Oil charge Circuit1 / Circuit 2 (l) 9.9/9.9 9.9/9.9 9.9/9.9
POE Oil type OIL048E or OIL023E
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
