Table 4 - RTWD High Seasonal Effi ciency - R134a
RTWD RTWD RTWD RTWD RTWD RTWD RTWD RTWD
60 70 80 90 100 110 120 130
Indicative performances
Cooling Capacity (1) (kW) 234.8 276.3 316.9 364.7 389.7 417.4 452.4 487.7
Total Power input in cooling (1) (kW) 49.4 58.8 67.7 76.9 81.4 86.6 93.5 100.8
Heating Capacity (2) (kW) 250.3 299.2 340.1 386.8 414.1 443.9 477.4 512.1
Total Power input in heating (2) (kW) 62.0 75.0 85.5 96.7 102.2 108.5 115.3 122.2
Compressor
Compressor Number per Circuit # 1/1 1/1 1/1 1/1 1/1 1/1 1/1 1/1
Type Screw
Model K1/K1 K2/K2 K2/L1 L1/L1 L1/L2 L2/L2 L2/M1 M1/M1
Evaporator
Quantity # 1 1 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model E1AM2 E1AM1 E1AMJ E2AM2 E2AM2 E2AM1 E2AMJ E3AM3
Evaporator Water Content volume (l) 37.0 40.2 45.2 57.9 57.9 62.3 65.4 72.6
Two pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 4.5 5.0 5.7 7.0 7.0 7.7 8.2 8.8
Evap. Water Flow rate - Maximum
(3)
(l/s) 16.6 18.4 21.1 25.7 25.7 28.2 30.0
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
DN100-4'
(114.3 mm)
DN100-4’
(114.3 mm)
DN100-4’
(114.3 mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
Three pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 3.0 3.3 3.8 4.7 4.7 5.1 5.4 5.9
Evap. Water Flow rate - Maximum
(3)
(l/s) 11.0 12.2 14.1 17.2 17.2 18.8 20.0 21.6
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
DN80-3'
(88.9 mm)
DN80-3'
(88.9 mm)
DN80-3'
(88.9 mm)
DN100-4'
(114.3 mm)
DN100-4'
(114.3 mm)
DN100-4'
(114.3 mm)
DN100-4'
(114.3 mm)
DN100-4'
(114.3 mm)
Condenser
Quantity # 1 1 1 1 1 1 1 1
Type Shell and Tube Heat Exchanger
Condenser model C1AM2 C1AM2 C1AMJ C2AM3 C2AM2 C2AM2 C2AMJ C3AM3
Condenser Water Content volume (l) 45.1 45.1 52.2 58.1 62.7 62.7 68.3 81.7
Two pass condenser
Cond. Water Flow rate - Minimum (l/s) 5.4 5.4 6.6 7.3 8.1 8.1 9.1 10.0
Cond. Water Flow rate - Maximum (l/s) 19.9 19.9 24.4 26.9 29.8 29.8 33.2 36.7
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
DN125-5’
(139.7 mm)
DN125-5’
(139.7 mm)
DN125-5’
(139.7 mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
DN125-5'
(139.7 mm)
DN150-6'
(168.3 mm)
Dimensions (4)
Unit Length (mm) 3320 3320 3320 3320 3320 3320 3320 3400
Unit Width (mm) 1130 1130 1130 1120 1120 1120 1120 1300
Unit Height (mm) 1940 1940 1940 1960 1960 1960 1960 1950
Weights (5)
Shipping Weight (kg) 2706 2711 2793 2986 3023 3057 3239 3790
Operating Weight (kg) 2788 2796 2829 3102 3144 3182 3372 3945
System data (6)
Nb of refrigerant circuit # 2 2 2 2 2 2 2 2
Minimum cooling load % % 30 30 30 30 30 30 30 30
Standard unit
R134a refrigerant charge Circuit1 /
Circuit 2 (6)
(kg) 45/45 45/45 45/44 55/55 55/56 55/55 54/54 61/61
Oil charge Circuit1 / Circuit 2 (l) 6.8/6.8 6.8/6.8 6.8/6.8 6.8/6.8 6.8/9.9 9.9/9.9 9.9/9.9 9.9/9.9
POE Oil type OIL048E or OIL023E
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
General data
