RLC-SVX14H-GB
14
Table 4 - RTWD High Seasonal Effi ciency - R134a (Continued)
RTWD RTWD RTWD RTWD RTWD RTWD RTWD RTWD
140 160 180 200 220 250 260 270
Indicative performances
Cooling Capacity (1) (kW) 531.1 597.7 658.5 708.6 765.4 836.4 900.6 979.5
Total Power input in cooling (1) (kW) 108.8 115.4 128.9 140.3 159.5 172.5 202.8 218.1
Heating Capacity (2) (kW) 562.2 629.2 691.1 744.0 812.9 888.4 959.0 1032.9
Total Power input in heating (2) (kW) 132.1 141.3 155.4 167.5 187.1 202.5 230.0 248.8
Compressor
Compressor Number per Circuit # 1/1 1/1 1/1 1/1 1/1 1/1 1/1 1/1
Type Screw
Model M1/M2 M2/M2 M2/N1 N1/N1 N1/N2 N2/N2 N1/N2 N2:N2
Evaporator
Quantity # 1 1 1 1 1 1 1 1
Type Flooded shell and tube heat exchanger
Evaporator model E3AM2 E3AM1 E3AMJ E5AM2 E5AM1 E5AMJ E5AMJ E5AMJ
Evaporator Water Content volume (l) 77.0 72.6 77.0 84.5 113.3 120.3 113.3 120.3
Two pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 9.5 11.7 12.7 15.1 14.1 15.1 14.1 15.1
Evap. Water Flow rate - Maximum
(3)
(l/s) 43.0 46.6 55.3
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
DN125-5’
(139.7 mm)
DN150-6’
(168.3 mm)
DN150-6’
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
Three pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 6.4 7.8 8.5 10.1 9.3 10.1 9.3 10.1
Evap. Water Flow rate - Maximum
(3)
(l/s) 23.3 28.6 31 36.9 34.3 36.9 34.3 36.9
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
DN100-4’
(114.3 mm)
DN100-4’
(114.3 mm)
DN100-4’
(114.3 mm)
DN100-4'
(114.3 mm)
DN100-4'
(114.3 mm)
DN100-4'
(114.3 mm)
DN100-4'
(114.3 mm)
DN100-4'
(114.3 mm)
Condenser
Quantity # 1 1 1 1 1 1 1 1
Type Shell and Tube Heat Exchanger
Condenser model C3AM2 C3AM1 C3AMJ C5AM2 C5AM2 C5AM1 C5AM1 C5AM1
Condenser Water Content volume (l) 86.8 93.0 99.0 118 117.8 133.3 117.8 133.3
Two pass condenser
Cond. Water Flow rate - Minimum (l/s) 10.9 5.4 5.4 6.6 15.4 18.0 15.4 18.0
Cond. Water Flow rate - Maximum (l/s) 39.9 19.9 19.9 24.4 56.4 65.9 56.4 65.9
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
DN150-6’
(168.3 mm)
DN150-6’
(168.3 mm)
DN150-6’
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
DN150-6'
(168.3 mm)
Dimensions (4)
Unit Length (mm) 3400 3830 3830 3490 3490 3490 3490 3490
Unit Width (mm) 1300 1300 1330 1340 1340 1340 1340 1340
Unit Height (mm) 1950 2010 2010 2010 2010 2010 2010 2010
Weights (5)
Shipping Weight (kg) 3832 4168 4389 4571 4487 4540 4487 4540
Operating Weight (kg) 3996 4386 4622 4839 4718 4793 4718 4793
System data (6)
Nb of refrigerant circuit # 2 2 2 2 2 2 2 2
Minimum cooling load % % 30 30 30 30 30 30 30 30
Standard unit
R134a refrigerant charge Circuit1 /
Circuit 2 (6)
(kg) 45/45 45/45 45/44 55/55 55/56 55/55 54/54 61/61
Oil charge Circuit1 / Circuit 2 (l) 6.8/6.8 6.8/6.8 6.8/6.8 6.8/6.8 6.8/9.9 9.9/9.9 9.9/9.9 9.9/9.9
POE Oil type OIL048E or OIL023E
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
General data
