Trane RTUD User Manual

RLC-SVX14H-GB
16
Table 5 - RTUD - R134a (Continued)
RTUD RTUD RTUD RTUD RTUD RTUD RTUD RTUD
140 160 170 180 190 200 220 250
Indicative performances
Cooling Capacity (1) (kW) 474 519 584 569 637 637 682 748
Total Power input in cooling (1) (kW) 120 130 157 145 171 171 175 190
Compressor
Compressor Number per Circuit # 1/1 1/1 1/1 1/1 1/1 1/1 1/1 1/1
Type Screw
Model M1/M2 M2/M2 N1/N1 M2/N1 N1/N2 N1/N1 N1/N2 N2/N2
Evaporator
Quantity # 1 1 1 11111
Type Flooded shell and tube heat exchanger
Evaporator model E3AM2 E3BM2 E3BM1 E3AMJ E3BM1 E5AM2 E5AM1 E5AMJ
Evaporator Water Content volume (l) 77.0 85.0 75.5 91.0 84.0 108.0 113.3 120.3
Two pass evaporator
Evap. Water Flow rate - Minimum
(2)
(l/s) 9.5 10.7 9.3 11.7 10.6 13.3 14.1 15.1
Evap. Water Flow rate - Maximum
(2)
(l/s) 34.9 39.1 34.1 43 38.9 48.6 51.5 55.3
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
6”
(168.3 mm)
6”
(168.3 mm)
6”
(168.3 mm)
Three pass evaporator
Evap. Water Flow rate - Minimum
(2)
(l/s) 6.4 7.13 6.2 7.82 7.1 8.83 9.3 10.1
Evap. Water Flow rate - Maximum
(2)
(l/s) 23.3 26.12 22.7 28.64 25.9 32.43 24.3 36.9
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
411
(114.3 mm)
411
(114.3 mm)
411
(114.3 mm)
411
(114.3 mm)
411
(114.3 mm)
411
(114.3 mm)
411
(114.3 mm)
411
(114.3 mm)
Condenser
Discharge Connection Diameter (in)
2"5/8 /
2"5/8
2"5/8 /
3"1/8
3"1/8 /
3"1/8
2"5/8 /
2"5/8
3"1/8 /
3"1/8
3"1/8 /
3"1/8
3"1/8 /
3"1/8
3"1/8 /
3"1/8
Liquid Connection Diameter (in)
1"3/8 /
1"3/8
1"3/8 /
1"3/8
1"3/8 /
1"3/8
1"3/8 /
1"3/8
1"3/8 /
1"5/8
1"3/8 /
1"3/8
1"3/8 /
1"5/8
1"5/8 /
1"5/8
Dimensions (3)
Unit Length (mm) 3400 3400 3490 3400 3490 3490 3490 3490
Unit Width (mm) 1280 1280 1310 1280 1310 1310 1310 1310
Unit Height (mm) 1950 1950 1970 1950 1970 2010 2010 2010
Weights (4)
Shipping Weight (kg) 3087 3225 3346 3393 3345 3476 3510 3525
Operating Weight (kg) 3164 3310 3421 3485 3429 3584 3623 3645
System data (5)
Nb of refrigerant circuit # 2 2 2 22222
Minimum cooling load % % 30 30 30 30 30 30 30 30
Standard unit
R134a refrigerant content
Circuit1 / Circuit 2
(kg) 30/30 30/30 30/30 30/30 30/30 30/30 30/30 30/30
Oil charge Circuit1 / Circuit 2 (6) (l)
POE Oil type OIL048E or OIL023E
Maximum R134a Refrigerant charge
in the system
177/177 173/173 170/170 177/177 191/191 189/189
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C (RTWD equivalent conditions) -
for detailed condenser condition and units performances consult order write up.
(2) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(3) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(4) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(5) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
(6) RTUD unit is shipped w/o oil - oil must be ordered separatly as it is not coming with unit.
General data
