RLC-SVX14H-GB
17
Table 6 - RTWD High Seasonal Effi ciency - R1234ze
RTWD RTWD RTWF RTWD RTWD RTWD
100 110 120 130 140 160
Indicative performances HSE HSE HSE HSE HSE HSE
Cooling Capacity (1) (kW) 368 402 438 482 534 587
Total Power input in cooling (1) (kW) 75 82 90 100 101 111
Heating Capacity (2) (kW) 397 434 473 520 576 633
Total Power input in heating (2) (kW) 85 93 101 112 113 126
Compressor
Compressor Number per Circuit # 1/1 1/1 1/1 1/1 1/1 1/1
Type Screw
Model M1/M1 M1/M2 M2/M2 M2/N5 N5/N5 N5/N6
Evaporator
Quantity # 111111
Type Flooded shell and tube heat exchanger
Evaporator model E3AM E3AM E3AM E3AM E4AM E4AM
Evaporator Water Content volume (l) 91 91 91 91 118 118
Two pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 11.8 11.8 11.8 11.8 12.7 12.7
Evap. Water Flow rate - Maximum (3) (l/s) 43.1 43.1 43.1 43.1 46.6 46.6
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
5" (139.7) 5" (139.7) 5" (139.7) 5" (139.7)
6” (168.3
mm)
6” (168.3
mm)
Three pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 7.8 7.8 7.8 7.8 8.5 8.5
Evap. Water Flow rate - Maximum (3) (l/s) 28.7 28.7 28.7 28.7 31.1 31.1
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
4”
(114.3 mm)
4”
(114.3 mm)
4”
(114.3 mm)
4”
(114.3 mm)
4”
(114.3 mm)
4”
(114.3 mm)
Condenser
Quantity # 111111
Type Shell and tube heat exchanger
Condenser model C3AM C3AM C3AM C3AM C4AM C4AM
Condenser Water Content volume (l) 99 99 99 99 131 131
Two pass condenser
Cond. Water Flow rate - Minimum (l/s) 13.0 13.0 13.0 13.0 15.4 15.4
Cond. Water Flow rate - Maximum (l/s) 47.6 47.6 47.6 47.6 56.5 56.5
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
6”
(168.3 mm)
6”
(168.3 mm)
6”
(168.3 mm)
6”
(168.3 mm)
6”
(168.3 mm)
6”
(168.3 mm)
Dimensions (4)
Unit Length (mm) 3395 3395 3395 3395 3811 3811
Unit Width (mm) 1148 1148 1148 1148 1155 1155
Unit Height (mm) 1943 1943 1943 1943 1998 1998
Weights (5)
Shipping Weight (kg) 3901 3902 3904 4060 4531 4533
Operating Weight (kg) 4092 4093 4095 4251 4780 4782
System data (6)
Nb of refrigerant circuit # 222222
Minimum cooling load % % 30 30 30 30 30 30
Standard unit
R1234ze refrigerant charge Circuit1 /
Circuit 2 (6)
(kg) 60/60 60/60 60/60 60/60 80/80 80/80
Oil charge Circuit1 / Circuit 2 (l) 9/9 9/9 9/9 11/11 11/11 11/11
POE Oil type OIL0066E or OIL0067E
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi
guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
General data
