General data
Table 6 - RTWD High Seasonal Effi ciency - R1234ze (Continued)
RTWD RTWD RTWD RTWD RTWD
170 180 200 220 250
Indicative performances HSE HSE HSE HSE HSE
Cooling Capacity (1) (kW) 642 689 718 765 814
Total Power input in cooling (1) (kW) 121 135 147 160 174
Heating Capacity (2) (kW) 691 748 788 845 902
Total Power input in heating (2) (kW) 138 154 168 183 198
Compressor
Compressor Number per Circuit # 1/1 1/1 1/1 1/1 1/1
Type Screw
Model N6/N6 N6/N6-60 N6-60/N6-60 N6-60/N6-70 N6-70/N6-70
Evaporator
Quantity # 11111
Type Flooded shell and tube heat exchanger
Evaporator model E4AM E4AM E5AM E5AM E5AM
Evaporator Water Content volume (l) 118 118 120 120 120
Two pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 12.7 12.7 15.1 15.1 15.1
Evap. Water Flow rate - Maximum (3) (l/s) 46.6 46.6 55.5 55.5 55.5
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
6” (168.3 mm) 6” (168.3 mm) 6” (168.3 mm) 6” (168.3 mm) 6” (168.3 mm)
Three pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 8.5 8.5 10.1 10.1 10.1
Evap. Water Flow rate - Maximum (3) (l/s) 31.1 31.1 37.0 37.0 37.0
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
4”
(114.3 mm)
4”
(114.3 mm)
4”
(114.3 mm)
4”
(114.3 mm)
4”
(114.3 mm)
Condenser
Quantity # 11111
Type Shell and tube heat exchanger
Condenser model C4AM C4AM C5AM C5AM C5AM
Condenser Water Content volume (l) 131 131 148 148 148
Two pass condenser
Cond. Water Flow rate - Minimum (l/s) 15.4 15.4 20.5 20.5 20.5
Cond. Water Flow rate - Maximum (l/s) 56.5 56.5 75.3 75.3 75.3
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
6” (168.3 mm) 6” (168.3 mm) 6” (168.3 mm) 6” (168.3 mm) 6” (168.3 mm)
Dimensions (4)
Unit Length (mm) 3811 3811 3489 3489 3489
Unit Width (mm) 1155 1155 1159 1159 1159
Unit Height (mm) 1998 1998 2004 2004 2004
Weights (5)
Shipping Weight (kg) 4535 4535 4572 4573 4575
Operating Weight (kg) 4784 4784 4841 4842 4844
System data (6)
Nb of refrigerant circuit # 22222
Minimum cooling load % % 30 27 25 23 21
Standard unit
R1234ze refrigerant charge Circuit1 /
Circuit 2 (6)
(kg) 80/80 80/80 80/80 80/80 80/80
Oil charge Circuit1 / Circuit 2 (l) 11/11 11/11 11/11 11/11 11/11
POE Oil type OIL0066E or OIL0067E
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
