Trane RTUD User Manual

RLC-SVX14H-GB
39
Table 13 - RTWD Standard Effi ciency R134a
Unit size 160 160 160 160 160 160 170 170 170 170 170 170
Unit Type Digit 12 1 1 1 1 1 1 1 1 1 1 1 1
Unit Application Digit 15 A A A B;C A B;C A A A B;C A B;C
Evap Application Digit 21 1 1 2;3 * 2;3 * 1 1 2;3 * 2;3 *
Comp Starter digit 24 Y B Y Y B B Y B Y Y B B
Compressor C1 M2 LoVi M2 LoVi M2 HiVi M2 HiVi M2 HiVi M2 HiVi N1 LoVi N1 LoVi N1 HiVi N1 HiVi N1 HiVi N1 HiVi
C2 N1 LoVi N1 LoVi N1 HiVi N1 HiVi N1 HiVi N1 HiVi N1 LoVi N1 LoVi N1 HiVi N1 HiVi N1 HiVi N1 HiVi
Circuit 1 Motor RLA (A) 98.0 98.0 98.0 132.8 98.0 132.8 116.8 116.8 116.8 160.8 116.8 160.8
Motor LRA (A) 259.0 0.0 259.0 259.0 0.0 0.0 291.0 0.0 291.0 291.0 0.0 0.0
Max Amps (A) 114.0 102.9 114.0 166.0 102.9 153.3 141.0 128.8 141.0 201.0 128.8 188.1
Max Power input (kW) 66.3 67.7 66.3 98.9 67.7 100.9 83.1 84.8 83.1 121.3 84.8 123.8
Circuit 2 Motor RLA (A) 116.8 116.8 116.8 160.8 116.8 160.8 116.8 116.8 116.8 160.8 116.8 160.8
Motor LRA (A) 291.0 0.0 291.0 291.0 0.0 0.0 291.0 0.0 291.0 291.0 0.0 0.0
Max Amps (A) 141.0 128.8 141.0 201.0 128.8 188.1 141.0 128.8 141.0 201.0 128.8 188.1
Max Power input (kW) 83.1 84.8 83.1 121.3 84.8 123.8 83.1 84.8 83.1 121.3 84.8 123.8
Unit @ Max Starting Amps (A) 407.0 233.7 407.0 462.0 233.7 343.4 434.0 259.6 434.0 494.0 259.6 378.1
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 257.0 233.7 257.0 369.0 233.7 343.4 284.0 259.6 284.0 404.0 259.6 378.1
displacement power
factor (DPF)
0.85 0.95 0.85 0.87 0.95 0.95 0.85 0.95 0.85 0.87 0.95 0.95
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35 35 35
Disconnect
Switch
Digit 26=C
Fuse size (A) C1 160 aM-T1200 gG-T1160 aM-T1200 aM-T2200 gG-T1200 gG-T2200 aM-T1200 gG-T1200 aM-T1250 aM-T2200 gG-T1250 aM-T2
Fuse size (A) C2 200 aM-T1200 gG-T1200 aM-T1250 aM-T2200 gG-T1250 aM-T2200 aM-T1200 gG-T1200 aM-T1250 aM-T2200 gG-T1250 aM-T2
Disconect Switch Size 6X250A -
T1
6X250A -
T1
6X250A -
T1
6X400A -
T2
6X250A -
T1
6X400A -
T2
6X250A -
T1
6X250A -
T1
6X250A -
T1
6X400A -
T2
6X250A -
T1
6X400A -
T2
Max connecting Wire
(mm²)
2 x 185 2 x 185 2 x 185 2 x 240 2 x 185 2 x 240 2 x 185 2 x 185 2 x 185 2 x 240 2 x 185 2 x 240
Bus bar width (mm) 32 32 32 45 32 45 32 32 32 45 32 45
Circuit Breaker +
Bus bar
Digit 26=D
circuit breaker size
(A) C1
NSX 160A NSX 160A NSX 160A NSX 250A NSX 160A NSX 250A NSX 160A NSX 160A NSX 160A NSX 250A NSX 160A NSX 250A
circuit breaker size
(A) C2
NSX 160A NSX 160A NSX 160A NSX 250A NSX 160A NSX 250A NSX 160A NSX 160A NSX 160A NSX 250A NSX 160A NSX 250A
Bus bar connection Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
