Trane RTUD User Manual

RLC-SVX14H-GB
40
Table 13 - RTWD Standard Effi ciency R134a (Continued)
Unit size 190 190 190 190 190 190 200 200 200 200 200 200
Unit Type Digit 12 1 1 1 1 1 1 1 1 1 1 1 1
Unit Application Digit 15 A A A B;C A B;C A A A B;C A B;C
Evap Application Digit 21 1 1 2;3 * 2;3 * 1 1 2;3 * 2;3 *
Comp Starter digit 24 Y B Y Y B B Y B Y Y B B
Compressor C1 N1 LoVi N1 LoVi N1 HiVi N1 HiVi N1 HiVi N1 HiVi N2 LoVi N2 LoVi N2 HiVi N2 HiVi N2 HiVi N2 HiVi
C2 N2 LoVi N2 LoVi N2 HiVi N2 HiVi N2 HiVi N2 HiVi N2 LoVi N2 LoVi N2 HiVi N2 HiVi N2 HiVi N2 HiVi
Circuit 1 Motor RLA (A) 116.8 116.8 116.8 160.8 116.8 160.8 140.8 140.8 132.8 192.0 132.8 192.0
Motor LRA (A) 291.0 0.0 291.0 291.0 0.0 0.0 354.0 0.0 354.0 354.0 0.0 0.0
Max Amps (A) 141.0 128.8 141.0 201.0 128.8 188.1 168.0 153.6 168.0 240.0 153.6 223.6
Max Power input (kW) 83.1 84.8 83.1 121.3 84.8 123.8 99.1 101.1 98.9 144.2 101.1 147.1
Circuit 2 Motor RLA (A) 140.8 140.8 132.8 192.0 132.8 192.0 140.8 140.8 132.8 192.0 132.8 192.0
Motor LRA (A) 354.0 0.0 354.0 354.0 0.0 0.0 354.0 0.0 354.0 354.0 0.0 0.0
Max Amps (A) 168.0 153.6 168.0 240.0 153.6 223.6 168.0 153.6 168.0 240.0 153.6 223.6
Max Power input (kW) 99.1 101.1 98.9 144.2 101.1 147.1 99.1 101.1 98.9 144.2 101.1 147.1
Unit @ Max Starting Amps (A) 497.0 284.4 497.0 557.0 284.4 413.6 524.0 309.2 524.0 597.0 309.2 449.1
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 3.0 2.0 2.0
Max. Amps (A) 311.0 284.4 311.0 443.0 284.4 413.6 338.0 309.2 338.0 482.0 309.2 449.1
displacement power
factor (DPF)
0.85 0.95 0.85 0.87 0.95 0.95 0.85 0.95 0.85 0.87 0.95 0.95
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 36 35 35
Disconnect
Switch
Digit 26=C
Fuse size (A) C1 200 aM-T1200 gG-T2200 aM-T1250 aM-T2200 gG-T2250 aM-T2250 aM-T1250 aM-T2250 aM-T1315 aM-T2250 aM-T2315 aM-T2
Fuse size (A) C2 250 aM-T1250 aM-T2250 aM-T1315 aM-T2250 aM-T2315 aM-T2250 aM-T1250 aM-T2250 aM-T1315 aM-T2250 aM-T2315 aM-T2
Disconect Switch Size 6X250A
- T1
6X400A
- T2
6X250A
- T1
6X400A
- T2
6X400A
- T2
6X400A
- T2
6X250A
- T1
6X400A
- T2
6X250A
- T1
6X400A
- T2
6X400A
- T2
6X400A
- T2
Max connecting Wire
(mm²)
2 x 185 2 x 240 2 x 185 2 x 240 2 x 240 2 x 240 2 x 185 2 x 240 2 x 185 2 x 240 2 x 240 2 x 240
Bus bar width (mm) 32 45 32 45 45 45 32 45 32 45 45 45
Circuit Breaker +
Bus bar
Digit 26=D
circuit breaker size
(A) C1
NSX 160A NSX 160A NSX 160A NSX 400A NSX 160A NSX 400A NSX 250A NSX 250A NSX 250A NSX 400A NSX 250A NSX 400A
circuit breaker size
(A) C2
NSX 250A NSX 250A NSX 250A NSX 400A NSX 250A NSX 400A NSX 250A NSX 250A NSX 250A NSX 400A NSX 250A NSX 400A
Bus bar connection Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x10
Copper
bar 50x8
Copper
bar 50x10
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x10
Copper
bar 50x8
Copper
bar 50x10
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
