RLC-SVX14H-GB
41
Table 14 - RTWD High Effi ciency R134a
Unit size 060 060 060 070 070 070 080 080 080 090 090
Unit Type Digit 12 2 2 2 2 2 2 2 2 2 2 2
Unit Application Digit 15 A A B;C A A B;C A A B;C A A
Evap Application Digit 21 1 2;3 * 1 2;3 * 1 2;3 * 1 2;3
Comp Starter digit 24 Y Y Y Y Y Y Y Y Y Y Y
Compressor C1 K1 LoVi K1 HiVi K1 HiVi K2 LoVi K2 HiVi K2 HiVi K2 LoVi K2 HiVi K2 HiVi L1 LoVi L1 HiVi
C2 K1 LoVi K1 HiVi K1 HiVi K2 LoVi K2 HiVi K2 HiVi L1 LoVi L1 HiVi L1 HiVi L1 LoVi L1 HiVi
Circuit 1 Motor RLA (A) 38.0 38.0 52.8 46.0 46.0 61.6 46.0 46.0 61.6 60.0 60.0
Motor LRA (A) 112.0 112.0 112.0 129.0 129.0 129.0 129.0 129.0 129.0 144.0 144.0
Max Amps (A) 43.0 43.0 66.0 53.0 53.0 77.0 53.0 53.0 77.0 68.0 68.0
Max Power input (kW) 26.5 26.5 41.7 31.4 31.4 49.3 31.4 31.4 49.3 41.5 41.5
Circuit 2 Motor RLA (A) 38.0 38.0 52.8 46.0 46.0 61.6 60.0 60.0 77.6 60.0 60.0
Motor LRA (A) 112.0 112.0 112.0 129.0 129.0 129.0 144.0 144.0 144.0 144.0 144.0
Max Amps (A) 43.0 43.0 66.0 53.0 53.0 77.0 68.0 68.0 97.0 68.0 68.0
Max Power input (kW) 26.5 26.5 41.7 31.4 31.4 49.3 41.5 41.5 60.1 41.5 41.5
Unit @ Max Starting Amps (A) 157.0 157.0 180.0 184.0 184.0 208.0 199.0 199.0 228.0 214.0 214.0
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 88.0 88.0 134.0 108.0 108.0 156.0 123.0 123.0 176.0 138.0 138.0
displacement power
factor (DPF)
0.89 0.89 0.91 0.85 0.85 0.92 0.87 0.87 0.91 0.88 0.88
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35 35
Disconnect Switch
Digit 26=C
Fuse size (A) C1 63 aM-T0063 aM-T0080 aM-T0080 aM-T0080 aM-T00 100 aM-
T00
80 aM-T0080 aM-T00 100 aM-
T00
100 aM-
T00
100 aM-
T00
Fuse size (A) C2 63 aM-T0063 aM-T0080 aM-T0080 aM-T0080 aM-T00 100 aM-
T00
125 aM-
T00
125 aM-
T00
125 aM-
T00
100 aM-
T00
100 aM-
T00
Disconect Switch Size 6X160A -
T00
6X160A -
T00
6X160A -
T00
6X160A -
T00
6X160A -
T00
6X160A -
T00
6X160A -
T00
6X160A -
T00
6X160A -
T00
6X160A -
T00
6X160A -
T00
Max connecting Wire
(mm²)
2 x 95 2 x 95 2 x 95 2 x 95 2 x 95 2 x 95 2 x 95 2 x 95 2 x 95 2 x 95 2 x 95
Bus bar width (mm) 20 20 20 20 20 20 20 20 20 20 20
Circuit Breaker +
Bus bar Digit 26=D
circuit breaker size (A)
C1
NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A
circuit breaker size (A)
C2
NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 100A NSX 160A NSX 100A NSX 100A
Bus bar connection Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
