Trane RTUD User Manual

RLC-SVX14H-GB
43
Table 14 - RTWD High Effi ciency R134a (Continued)
Unit size 130 130 140 140 140 160 160 160 180 180
Unit Type Digit 12 2 2 2 2222222
Unit Application Digit 15 A B;C A A B;C A A B;C A A
Evap Application Digit 21 2;3 * 1 2;3 * 1 2;3 * 1 2;3
Comp Starter digit 24 Y YYYYYYYYY
Compressor C1 M1 HiVi M1 HiVi M1 LoVi M1 HiVi M1 HiVi M2 LoVi M2 HiVi M2 HiVi M2 LoVi M2 HiVi
C2 M1 HiVi M1 HiVi M2 LoVi M2 HiVi M2 HiVi M2 LoVi M2 HiVi M2 HiVi N1 LoVi N1 HiVi
Circuit 1 Motor RLA (A) 84.8 112.8 84.8 84.8 112.8 98.0 98.0 132.8 98.0 98.0
Motor LRA (A) 217.0 217.0 217.0 217.0 217.0 259.0 259.0 259.0 259.0 259.0
Max Amps (A) 94.0 141.0 94.0 94.0 141.0 114.0 114.0 166.0 114.0 114.0
Max Power input (kW) 54.8 83.3 54.8 54.8 83.3 66.3 66.3 98.9 66.3 66.3
Circuit 2 Motor RLA (A) 84.8 112.8 98.0 98.0 132.8 98.0 98.0 132.8 116.8 116.8
Motor LRA (A) 217.0 217.0 259.0 259.0 259.0 259.0 259.0 259.0 291.0 291.0
Max Amps (A) 94.0 141.0 114.0 114.0 166.0 114.0 114.0 166.0 141.0 141.0
Max Power input (kW) 54.8 83.3 66.3 66.3 98.9 66.3 66.3 98.9 83.1 83.1
Unit @ Max Starting Amps (A) 313.0 360.0 355.0 355.0 402.0 375.0 375.0 427.0 407.0 407.0
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 190.0 284.0 210.0 210.0 309.0 230.0 230.0 334.0 257.0 257.0
displacement power
factor (DPF)
0.84 0.85 0.84 0.84 0.86 0.84 0.84 0.86 0.85 0.85
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35
Disconnect Switch
Digit 26=C
Fuse size (A) C1 125 aM-T1 160 aM-T1 125 aM-T1 125 aM-T1 160 aM-T1 160 aM-T1 160 aM-T1 200 aM-T1 160 aM-T1 160 aM-T1
Fuse size (A) C2 125 aM-T1 160 aM-T1 160 aM-T1 160 aM-T1 200 aM-T1 160 aM-T1 160 aM-T1 200 aM-T1 200 aM-T1 200 aM-T1
Disconect Switch Size 6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
Max connecting Wire
(mm²)
2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185
Bus bar width (mm) 32 32 32 32 32 32 32 32 32 32
Circuit Breaker + Bus bar
Digit 26=D
circuit breaker size (A) C1 NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A
circuit breaker size (A) C2 NSX 160A NSX 160A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A
Bus bar connection Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
