Trane RTUD User Manual

RLC-SVX14H-GB
44
Table 14 - RTWD High Effi ciency R134a (Continued)
Unit size 180 200 200 200 220 220 220 250 250 250
Unit Type Digit 12 2 2 2 2222222
Unit Application Digit 15 B;C A A B;C A A B;C A A B;C
Evap Application Digit 21 * 1 2;3 * 1 2;3 * 1 2;3 *
Comp Starter digit 24 Y YYYYYYYYY
Compressor C1 M2 HiVi N1 LoVi N1 HiVi N1 HiVi N1 LoVi N1 HiVi N1 HiVi N2 LoVi N2 HiVi N2 HiVi
C2 N1 HiVi N1 LoVi N1 HiVi N1 HiVi N2 LoVi N2 HiVi N2 HiVi N2 LoVi N2 HiVi N2 HiVi
Circuit 1 Motor RLA (A) 132.8 116.8 116.8 160.8 116.8 116.8 160.8 140.8 132.8 192.0
Motor LRA (A) 259.0 291.0 291.0 291.0 291.0 291.0 291.0 354.0 354.0 354.0
Max Amps (A) 166.0 141.0 141.0 201.0 141.0 141.0 201.0 168.0 168.0 240.0
Max Power input (kW) 98.9 83.1 83.1 121.3 83.1 83.1 121.3 99.1 98.9 144.2
Circuit 2 Motor RLA (A) 160.8 116.8 116.8 160.8 140.8 132.8 192.0 140.8 132.8 192.0
Motor LRA (A) 291.0 291.0 291.0 291.0 354.0 354.0 354.0 354.0 354.0 354.0
Max Amps (A) 201.0 141.0 141.0 201.0 168.0 168.0 240.0 168.0 168.0 240.0
Max Power input (kW) 121.3 83.1 83.1 121.3 99.1 98.9 144.2 99.1 98.9 144.2
Unit @ Max Starting Amps (A) 462.0 434.0 434.0 494.0 497.0 497.0 557.0 524.0 524.0 596.0
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 369.0 284.0 284.0 404.0 311.0 311.0 443.0 338.0 338.0 482.0
displacement power
factor (DPF)
0.87 0.85 0.85 0.87 0.85 0.85 0.87 0.85 0.85 0.87
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35
Disconnect Switch
Digit 26=C
Fuse size (A) C1 200 aM-T2 200 aM-T1 200 aM-T1 250 aM-T2 200 aM-T1 200 aM-T1 250 aM-T2 250 aM-T1 250 aM-T1 315 aM-T2
Fuse size (A) C2 250 aM-T2 200 aM-T1 200 aM-T1 250 aM-T2 250 aM-T1 250 aM-T1 315 aM-T2 250 aM-T1 250 aM-T1 315 aM-T2
Disconect Switch Size 6X400A
- T2
6X250A
- T1
6X250A
- T1
6X400A
- T2
6X250A
- T1
6X250A
- T1
6X400A
- T2
6X250A
- T1
6X250A
- T1
6X400A
- T2
Max connecting Wire
(mm²)
2 x 240 2 x 185 2 x 185 2 x 240 2 x 185 2 x 185 2 x 240 2 x 185 2 x 185 2 x 240
Bus bar width (mm) 45 32 32 45 32 32 45 32 32 45
Circuit Breaker + Bus bar
Digit 26=D
circuit breaker size (A) C1 NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 400A NSX 250A NSX 250A NSX 400A
circuit breaker size (A) C2 NSX 250A NSX 160A NSX 160A NSX 250A NSX 250A NSX 250A NSX 400A NSX 250A NSX 250A NSX 400A
Bus bar connection Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x10
Copper bar
50x8
Copper bar
50x8
Copper bar
50x10
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
