Trane RTUD User Manual

RLC-SVX14H-GB
45
Table 15 - RTWD Extra High Effi ciency R134a
Unit size 160 160 160 160 160 160 180 180
Unit Type Digit 12 3 3333333
Unit Application Digit 15 AAAAB;CB;CAA
Evap Application Digit 21 1 1 2;3 2;3 * * 1 1
Comp Starter digit 24 YBYBBYYB
Compressor C1 M2 LoVi M2 LoVi M2 HiVi M2 HiVi M2 HiVi M2 HiVi M2 LoVi M2 LoVi
C2 M2 LoVi M2 LoVi M2 HiVi M2 HiVi M2 HiVi M2 HiVi N1 LoVi N1 LoVi
Circuit 1 Motor RLA (A) 98.0 98.0 98.0 98.0 132.8 132.8 98.0 98.0
Motor LRA (A) 259.0 0.0 259.0 0.0 0.0 259.0 259.0 0.0
Max Amps (A) 114.0 102.9 114.0 102.9 153.3 166.0 114.0 102.9
Max Power input (kW) 66.3 67.7 66.3 67.7 100.9 98.9 66.3 67.7
Circuit 2 Motor RLA (A) 98.0 98.0 98.0 98.0 132.8 132.8 116.8 116.8
Motor LRA (A) 259.0 0.0 259.0 0.0 0.0 259.0 291.0 0.0
Max Amps (A) 114.0 102.9 114.0 102.9 153.3 166.0 141.0 128.8
Max Power input (kW) 66.3 67.7 66.3 67.7 100.9 98.9 83.1 84.8
Unit @ Max Starting Amps (A) 375.0 207.7 375.0 207.7 308.7 427.0 407.0 233.7
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 230.0 207.7 230.0 207.7 308.7 334.0 257.0 233.7
displacement power factor (DPF) 0.84 0.95 0.84 0.95 0.95 0.86 0.85 0.95
short circuit withstand rating
(kA)
35 35 35 35 35 35 35 35
Disconnect Switch Digit 26=C Fuse size (A) C1 160 aM-T1 200 gG-T1 200 aM-T1 200 gG-T1 200 gG-T1 200 aM-T1 160 aM-T1 200 gG-T1
Fuse size (A) C2 160 aM-T1 200 gG-T1 200 aM-T1 200 gG-T1 200 gG-T1 200 aM-T1 200 aM-T1 200 gG-T1
Disconect Switch Size 6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
Max connecting Wire (mm²) 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185
Bus bar width (mm) 32 32 32 32 32 32 32 32
Circuit Breaker + Bus bar
Digit 26=D
circuit breaker size (A) C1 NSX 160A NSX 160A NSX 160A NSX 160A NSX 250A NSX 250A NSX 160A NSX 160A
circuit breaker size (A) C2 NSX 160A NSX 160A NSX 160A NSX 160A NSX 250A NSX 250A NSX 160A NSX 160A
Bus bar connection Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Max connecting Wire (mm²) 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
