46
Table 15 - RTWD Extra High Effi ciency R134a (Continued)
Unit size 180 180 180 200 200 200 200 200
Unit Type Digit 12 3 3 333333
Unit Application Digit 15 A A B;C A A A A B;C
Evap Application Digit 21 2;3 2;3 * 1 1 2;3 2;3 *
Comp Starter digit 24 Y B B Y B Y B B
Compressor C1 M2 HiVi M2 HiVi M2 HiVi N1 LoVi N1 LoVi N1 HiVi N1 HiVi N1 HiVi
C2 N1 HiVi N1 HiVi N1 HiVi N1 LoVi N1 LoVi N1 HiVi N1 HiVi N1 HiVi
Circuit 1 Motor RLA (A) 98.0 98.0 132.8 116.8 116.8 116.8 116.8 160.8
Motor LRA (A) 259.0 0.0 0.0 291.0 0.0 291.0 0.0 0.0
Max Amps (A) 114.0 102.9 153.3 141.0 128.8 141.0 128.8 188.1
Max Power input (kW) 66.3 67.7 100.9 83.1 84.8 83.1 84.8 123.8
Circuit 2 Motor RLA (A) 116.8 116.8 160.8 116.8 116.8 116.8 116.8 160.8
Motor LRA (A) 291.0 0.0 0.0 291.0 0.0 291.0 0.0 0.0
Max Amps (A) 141.0 128.8 188.1 141.0 128.8 141.0 128.8 188.1
Max Power input (kW) 83.1 84.8 123.8 83.1 84.8 83.1 84.8 123.8
Unit @ Max Starting Amps (A) 407.0 233.7 343.4 434.0 259.6 434.0 259.6 378.1
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 257.0 233.7 343.4 284.0 259.6 284.0 259.6 378.1
displacement power factor (DPF) 0.85 0.95 0.95 0.85 0.95 0.85 0.95 0.95
short circuit withstand rating
(kA)
35 35 35 35 35 35 35 35
Disconnect Switch Digit 26=C Fuse size (A) C1 160 aM-T1 200 gG-T1 200 gG-T2 200 aM-T1 200 gG-T1 200 aM-T1 200 gG-T1 250 aM-T2
Fuse size (A) C2 200 aM-T1 200 gG-T1 250 aM-T2 200 aM-T1 200 gG-T1 200 aM-T1 200 gG-T1 250 aM-T2
Disconect Switch Size 6X250A
- T1
6X250A
- T1
6X400A
- T2
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X250A
- T1
6X400A
- T2
Max connecting Wire (mm²) 2 x 185 2 x 185 2 x 240 2 x 185 2 x 185 2 x 185 2 x 185 2 x 240
Bus bar width (mm) 32 32 45 32 32 32 32 45
Circuit Breaker + Bus bar
Digit 26=D
circuit breaker size (A) C1 NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 160A NSX 160A NSX 250A
circuit breaker size (A) C2 NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 160A NSX 160A NSX 250A
Bus bar connection Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Max connecting Wire (mm²) 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
