Trane RTUD User Manual

RLC-SVX14H-GB
49
Table 16 - RTWD High Seasonal Effi ciency R134a (Continued)
Unit size 140 140 140 160 160 160 180 180 180 200 200 200
Unit Type Digit 12 2 2 2 2 2 2 2 2 2 2 2 2
Unit Application Digit 15 A A B;C A A B;C A A B;C A A B;C
Evap Application Digit 21 1 2;3 * 1 2;3 * 1 2;3 * 1 2;3 *
Comp Starter digit 24 B B B B B B B B B B B B
Compressor C1 M1 LoVi M1 HiVi M1 HiVi M2 LoVi M2 HiVi M2 HiVi M2 LoVi M2 HiVi M2 HiVi N1 LoVi N1 HiVi N1 HiVi
C2 M2 LoVi M2 HiVi M2 HiVi M2 LoVi M2 HiVi M2 HiVi N1 LoVi N1 HiVi N1 HiVi N1 LoVi N1 HiVi N1 HiVi
Circuit 1 Motor RLA (A) 84.8 84.8 112.8 98.0 98.0 132.8 98.0 98.0 132.8 116.8 116.8 160.8
Motor LRA (A) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Amps (A) 85.0 85.0 129.1 102.9 102.9 153.3 102.9 102.9 153.3 128.8 128.8 188.1
Max Power input (kW) 56.0 56.0 85.0 67.7 67.7 100.9 67.7 67.7 100.9 84.8 84.8 123.8
Circuit 2 Motor RLA (A) 98.0 98.0 132.8 98.0 98.0 132.8 116.8 116.8 160.8 116.8 116.8 160.8
Motor LRA (A) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Amps (A) 102.9 102.9 153.3 102.9 102.9 153.3 128.8 128.8 188.1 128.8 128.8 188.1
Max Power input (kW) 67.7 67.7 100.9 67.7 67.7 100.9 84.8 84.8 123.8 84.8 84.8 123.8
Unit @ Max Starting Amps (A) 189.9 189.9 284.5 207.7 207.7 308.7 233.7 233.7 343.4 259.6 259.6 378.1
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 189.9 189.9 284.5 207.7 207.7 308.7 233.7 233.7 343.4 259.6 259.6 378.1
displacement power
factor (DPF)
0.950 0.950 0.950 0.950 0.950 0.950 0.950 0.950 0.950 0.950 0.950 0.950
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35 35 35
Disconnect
Switch
Digit 26=C
Fuse size (A) C1 160 gG-T1160 gG-T1200 gG-T1200 gG-T1200 gG-T1200 gG-T1200 gG-T1200 gG-T1200 gG-T2200 gG-T1200 gG-T1250 aM-T2
Fuse size (A) C2 200 gG-T1200 gG-T1200 gG-T1200 gG-T1200 gG-T1200 gG-T1200 gG-T1200 gG-T1250 aM-T2200 gG-T1200 gG-T1250 aM-T2
Disconect Switch Size 6X250A -
T1
6X250A -
T1
6X250A -
T1
6X250A -
T1
6X250A -
T1
6X250A -
T1
6X250A -
T1
6X250A -
T1
6X400A -
T2
6X250A -
T1
6X250A -
T1
6X400A -
T2
Max connecting Wire
(mm²)
2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 240 2 x 185 2 x 185 2 x 240
Bus bar width (mm) 32 32 32 32 32 32 32 32 45 32 32 45
Circuit Breaker +
Bus bar
Digit 26=D
circuit breaker size
(A) C1
NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A
circuit breaker size
(A) C2
NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A
Bus bar connection Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
