Table 18 - RTWD High Effi ciency R1234ze (Continued)
Unit size 130 140 140 140 160 160 160 170 170 170
Unit Type Digit 12 2 2 2 2222222
Unit Application Digit 15 B;C A A B;C A A B;C A A B;C
Evap Application Digit 21 * 1 2;3 * 1 2;3 * 1 2;3 *
Comp Starter digit 24 Y YYYYYYYYY
Compressor C1 M2 HiVi N5 HiVi N5 HiVi N5 HiVi N5 HiVi N5 HiVi N5 HiVi N6 HiVi N6 HiVi N6 HiVi
C2 N5 HiVi N5 HiVi N5 HiVi N5 HiVi N6 HiVi N6 HiVi N6 HiVi N6 HiVi N6 HiVi N6 HiVi
Circuit 1 Motor RLA (A) 113.6 87.2 87.2 130.4 87.2 87.2 130.4 107.2 107.2 163.2
Motor LRA (A) 259.0 291.0 291.0 291.0 291.0 291.0 291.0 354.0 354.0 354.0
Max Amps (A) 142.0 109.0 109.0 163.0 109.0 109.0 163.0 134.0 134.0 204.0
Max Power input (kW) 87.0 63.0 63.0 98.0 63.0 63.0 98.0 79.0 79.0 125.0
Circuit 2 Motor RLA (A) 130.4 87.2 87.2 130.4 107.2 107.2 163.2 107.2 107.2 163.2
Motor LRA (A) 291.0 291.0 291.0 291.0 354.0 354.0 354.0 354.0 354.0 354.0
Max Amps (A) 163.0 109.0 109.0 163.0 134.0 134.0 204.0 134.0 134.0 204.0
Max Power input (kW) 98.0 63.0 63.0 98.0 79.0 79.0 125.0 79.0 79.0 125.0
Unit @ Max Starting Amps (A) 435.0 348.0 348.0 456.0 395.0 395.0 519.0 420.0 420.0 560.0
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 307.0 220.0 220.0 328.0 245.0 245.0 369.0 270.0 270.0 410.0
displacement power
factor (DPF)
0.88 0.83 0.83 0.87 0.84 0.84 0.88 0.85 0.85 0.88
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35
Disconnect Switch
Digit 26=C
Fuse size (A) C1 200 aM-T2 200 aM-T1 200 aM-T1 250 aM-T2 200 aM-T1 200 aM-T1 250 aM-T2 250 aM-T1 250 aM-T1 315 aM-T2
Fuse size (A) C2 250 aM-T2 200 aM-T1 200 aM-T1 250 aM-T2 250 aM-T1 250 aM-T1 315 aM-T2 250 aM-T1 250 aM-T1 315 aM-T2
Disconect Switch Size 6X400A -
T2
6X250A -
T1
6X250A -
T1
6X400A -
T2
6X250A -
T1
6X250A -
T1
6X400A -
T2
6X250A -
T1
6X250A -
T1
6X400A -
T2
Max connecting Wire
(mm²)
2 x 240 2 x 185 2 x 185 2 x 240 2 x 185 2 x 185 2 x 240 2 x 185 2 x 185 2 x 240
Bus bar width (mm) 45 32 32 45 32 32 45 32 32 45
Circuit Breaker + Bus bar
Digit 26=D
circuit breaker size (A) C1 NSX 160A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A
circuit breaker size (A) C2 NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A
Bus bar connection Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Copper bar
50x8
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
