Trane RTUD User Manual

RLC-SVX14H-GB
56
Table 19 - RTWD High Seasonal Effi ciency R1234ze
Unit size 100 100 100 110 110 110 120 120 120 130 130
Unit Type Digit 12 2 2 2 2 2 2 2 2 2 2 2
Unit Application Digit 15 A A B;C A A B;C A A B;C A A
Evap Application Digit 21 1 2;3 * 1 2;3 * 1 2;3 * 1 2;3
Comp Starter digit 24 B B B B B B B B B B B
Compressor C1 M1 HiVi M1 HiVi M1 HiVi M1 HiVi M1 HiVi M1 HiVi M2 HiVi M2 HiVi M2 HiVi M2 HiVi M2 HiVi
C2 M1 HiVi M1 HiVi M1 HiVi M2 HiVi M2 HiVi M2 HiVi M2 HiVi M2 HiVi M2 HiVi N5 HiVi N5 HiVi
Circuit 1 Motor RLA (A) 65.6 65.6 95.2 65.6 65.6 95.2 78.4 78.4 113.6 78.4 78.4
Motor LRA (A) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Amps (A) 72.9 72.9 113.2 72.9 72.9 113.2 89.9 89.9 134.9 89.9 89.9
Max Power input (kW) 48.0 48.0 74.5 48.0 48.0 74.5 59.2 59.2 88.8 59.2 59.2
Circuit 2 Motor RLA (A) 65.6 65.6 95.2 78.4 78.4 113.6 78.4 78.4 113.6 91.2 91.2
Motor LRA (A) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Amps (A) 72.9 72.9 113.2 89.9 89.9 134.9 89.9 89.9 134.9 103.9 103.9
Max Power input (kW) 48.0 48.0 74.5 59.2 59.2 88.8 59.2 59.2 88.8 68.4 68.4
Unit @ Max Starting Amps (A) 147.7 147.7 228.4 164.8 164.8 250.1 181.8 181.8 271.8 195.8 195.8
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 147.7 147.7 228.4 164.8 164.8 250.1 181.8 181.8 271.8 195.8 195.8
displacement power
factor (DPF)
0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35 35
Disconnect Switch
Digit 26=C
Fuse size (A) C1 125 gG-
T00
125 gG-
T00
200 gG-T1 125 gG-
T00
125 gG-
T00
200 gG-T1160 gG-T1160 gG-T1200 gG-T1160 gG-T1160 gG-T1
Fuse size (A) C2 125 gG-
T00
125 gG-
T00
200 gG-T1 160 gG-
T00
160 gG-
T00
200 gG-T1160 gG-T1160 gG-T1200 gG-T1200 gG-T1200 gG-T1
Disconect Switch Size 6X160A -
T00
6X160A -
T00
6X250A -
T1
6X160A -
T00
6X160A -
T00
6X250A -
T1
6X250A -
T1
6X250A -
T1
6X250A -
T1
6X250A -
T1
6X250A -
T1
Max connecting Wire
(mm²)
2 x 95 2 x 95 2 x 185 2 x 95 2 x 95 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185 2 x 185
Bus bar width (mm) 20 20 32 20 20 32 32 32 32 32 32
Circuit Breaker +
Bus bar Digit 26=D
circuit breaker size (A)
C1
NSX 100A NSX 100A NSX 160A NSX 100A NSX 100A NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A
circuit breaker size (A)
C2
NSX 100A NSX 100A NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A NSX 160A
Bus bar connection Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
