Trane RTUD User Manual

RLC-SVX14H-GB
57
Table 19 - RTWD High Seasonal Effi ciency R1234ze (Continued)
Unit size 130 140 140 140 160 160 160 170 170 170 180
Unit Type Digit 12 2 2 2 2 2 2 2 2 2 2 2
Unit Application Digit 15 B;C A A B;C A A B;C A A B;C A
Evap Application Digit 21 * 1 2;3 * 1 2;3 * 1 2;3 * 1
Comp Starter digit 24 B B B B B B B B B B B
Compressor C1 M2 HiVi N5 HiVi N5 HiVi N5 HiVi N5 HiVi N5 HiVi N5 HiVi N6 HiVi N6 HiVi N6 HiVi N6 HiVi
C2 N5 HiVi N5 HiVi N5 HiVi N5 HiVi N6 HiVi N6 HiVi N6 HiVi N6 HiVi N6 HiVi N6 HiVi N6E2 60
HiVi
Circuit 1 Motor RLA (A) 113.6 91.2 91.2 148.8 91.2 91.2 148.8 108.8 108.8 170.4 108.8
Motor LRA (A) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Amps (A) 134.9 103.9 103.9 170.5 103.9 103.9 170.5 124.0 124.0 203.1 124.0
Max Power input (kW) 88.8 68.4 68.4 112.2 68.4 68.4 112.2 81.6 81.6 133.7 81.6
Circuit 2 Motor RLA (A) 148.8 91.2 91.2 148.8 108.8 108.8 170.4 108.8 108.8 170.4 128.0
Motor LRA (A) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Amps (A) 170.5 103.9 103.9 170.5 124.0 124.0 203.1 124.0 124.0 203.1 150.4
Max Power input (kW) 112.2 68.4 68.4 112.2 81.6 81.6 133.7 81.6 81.6 133.7 99.0
Unit @ Max Starting Amps (A) 307.4 209.7 209.7 343.1 229.9 229.9 375.6 250.1 250.1 408.2 276.4
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 307.4 209.7 209.7 343.1 229.9 229.9 375.6 250.1 250.1 408.2 276.4
displacement power
factor (DPF)
0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35 35
Disconnect Switch
Digit 26=C
Fuse size (A) C1 200 gG-T2200 gG-T1200 gG-T1250 aM-T2200 gG-T1200 gG-T1250 aM-T2200 gG-T1200 gG-T1250 aM-T2200 gG-T2
Fuse size (A) C2 250 aM-T2200 gG-T1200 gG-T1250 aM-T2200 gG-T1200 gG-T1250 aM-T2200 gG-T1200 gG-T1250 aM-T2250 aM-T2
Disconect Switch Size 6X400A -
T2
6X250A -
T1
6X250A -
T1
6X400A -
T2
6X250A -
T1
6X250A -
T1
6X400A -
T2
6X250A -
T1
6X250A -
T1
6X400A -
T2
6X400A -
T2
Max connecting Wire
(mm²)
2 x 240 2 x 185 2 x 185 2 x 240 2 x 185 2 x 185 2 x 240 2 x 185 2 x 185 2 x 240 2 x 240
Bus bar width (mm) 45 32 32 45 32 32 45 32 32 45 45
Circuit Breaker +
Bus bar Digit 26=D
circuit breaker size (A)
C1
NSX 160A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A
circuit breaker size (A)
C2
NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 160A NSX 160A NSX 250A NSX 250A
Bus bar connection Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x8
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
