Trane RTUD User Manual

RLC-SVX14H-GB
58
Table 19 - RTWD High Seasonal Effi ciency R1234ze (Continued)
Unit size 180 180 200 200 200 220 220 220 250 250 250
Unit Type Digit 12 2 2 2 2 2 2 2 2 2 2 2
Unit Application Digit 15 A B;C A A B;C A A B;C A A B;C
Evap Application Digit 21 2;3 * 1 2;3 * 1 2;3 * 1 2;3 *
Comp Starter digit 24 B B B B B B B B B B B
Compressor C1 N6 HiVi N6 HiVi N6E2 60
HiVi
N6E2 60
HiVi
N6E2 60
HiVi
N6E2 60
HiVi
N6E2 60
HiVi
N6E2 60
HiVi
N6E2 70
HiVi
N6E2 70
HiVi
N6E2 70
HiVi
C2 N6E2 60
HiVi
N6E2 60
HiVi
N6E2 60
HiVi
N6E2 60
HiVi
N6E2 60
HiVi
N6E2 70
HiVi
N6E2 70
HiVi
N6E2 70
HiVi
N6E2 70
HiVi
N6E2 70
HiVi
N6E2 70
HiVi
Circuit 1 Motor RLA (A) 108.8 170.4 128.0 128.0 204.8 128.0 128.0 204.8 146.4 146.4 236.8
Motor LRA (A) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Amps (A) 124.0 203.1 150.4 150.4 235.7 150.4 150.4 235.7 172.1 172.1 271.3
Max Power input (kW) 81.6 133.7 99.0 99.0 155.1 99.0 99.0 155.1 113.3 113.3 178.6
Circuit 2 Motor RLA (A) 128.0 204.8 128.0 128.0 204.8 146.4 146.4 236.8 146.4 146.4 236.8
Motor LRA (A) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Amps (A) 150.4 235.7 150.4 150.4 235.7 172.1 172.1 271.3 172.1 172.1 271.3
Max Power input (kW) 99.0 155.1 99.0 99.0 155.1 113.3 113.3 178.6 113.3 113.3 178.6
Unit @ Max Starting Amps (A) 276.4 440.7 302.8 302.8 473.3 324.5 324.5 509.0 346.2 346.2 544.6
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 276.4 440.7 302.8 302.8 473.3 324.5 324.5 509.0 346.2 346.2 544.6
displacement power
factor (DPF)
0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95 0.95
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35 35
Disconnect Switch
Digit 26=C
Fuse size (A) C1 200 gG-T2250 aM-T2250 aM-T2250 aM-T2315 aM-T2250 aM-T2250 aM-T2315 aM-T2250 aM-T2250 aM-T2315 aM-T2
Fuse size (A) C2 250 aM-T2315 aM-T2250 aM-T2250 aM-T2315 aM-T2250 aM-T2250 aM-T2315 aM-T2250 aM-T2250 aM-T2315 aM-T2
Disconect Switch Size 6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
Bus bar width (mm) 45 45 45 45 45 45 45 45 45 45 45
Circuit Breaker +
Bus bar Digit 26=D
circuit breaker size (A)
C1
NSX 160A NSX 400A NSX 250A NSX 250A NSX 400A NSX 250A NSX 250A NSX 400A NSX 250A NSX 250A NSX 400A
circuit breaker size (A)
C2
NSX 250A NSX 400A NSX 250A NSX 250A NSX 400A NSX 250A NSX 250A NSX 400A NSX 250A NSX 250A NSX 400A
Bus bar connection Copper
bar 50x8
Copper
bar 50x10
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x10
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x10
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x10
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
